DisplayPort to Mini DisplayPort Cable Adapter, 4K x

2K/3840 x 2160 (M/F), 6 in.

MODEL NUMBER: P134-06N-MDP

Description

The P134-06N-MDP DisplayPort to Mini DisplayPort Cable Adapter connects a DisplayPort computer to a Mini

DisplayPort monitor. It allows you to continue using your existing mDP display instead of buying a new

DisplayPort monitor.

Ideal for displaying crystal-clear video on a large monitor or digital sign, this six-inch cable supports Ultra High Definition (UHD) video resolutions up to 3840 x

2160 (4K x 2K), including 1080p. This adapter is designed for use with both Single-Mode and Dual-Mode (DP++) DisplayPort graphics cards.

Gold-plated connectors and contacts ensure excellent conductivity. Integral strain relief ensures the cable and molded connectors last a long time. Just plug

and play with no software or drivers required.

Features

Sends UHD DisplayPort Audio/Video to a Mini DisplayPort Monitor

Connects a DisplayPort computer to an mDP monitor

Recommended for displaying DisplayPort video on a large monitor or digital sign

Allows you to continue using an existing mDP display, instead of buying a new monitor

Vibrant, Superior Video Quality

Supports UHD video resolutions up to 3840 x 2160 (4K x 2K), including 1080p

Works with both Single-Mode and Dual-Mode (DP++) DisplayPort graphics cards

Superior Materials for Superior Performance

Gold-plated connectors and contacts for excellent conductivity

Integral strain relief for long life

Plug and play—no software or drivers required

Highlights

Supports UHD video resolutions

up to 3840 x 2160 (4K x 2K)

Works with both Single-Mode

and Dual-Mode graphics cards

Gold-plated connectors and

contacts

Integral strain relief

Plug and play—no software or

drivers required

System Requirements

Computer with a DisplayPort

output

Monitor with a Mini DisplayPort

input

Package Includes

P134-06N-MDP DisplayPort to

Mini DisplayPort Cable Adapter

(M/F), 6 in.

1 / 2

Specifications

INPUT

Cable Length (ft.) 0.05

Cable Length (m) 0.2

Cable Length (in.) 6

PHYSICAL

Color White

CONNECTIONS

Side A - Connector 1 DISPLAYPORT (MALE)

Side B - Connector 1 MINI DISPLAYPORT (FEMALE)

CERTIFICATIONS

Certifications RoHS

WARRANTY

Product Warranty Period (Worldwide) 1-year limited warranty

not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:

http://www.tripplite.com/products/product-certification-agencies

2 / 2

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	kabler for datamaskiner og annet
Modell:	P134-06N-MDP
Vekt:	30 g
Bredde:	38.1 mm
Dybde:	41.9 mm
Høyde:	20.1 mm
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Vietnam
Pakkevekt:	270 g
Antall per pakke:	1 stykker
Tilkobling 1:	DisplayPort
Tilkobling 2:	Mini DisplayPort
Kabellengde:	0.2 m
Produktfarge:	Hvit
Pakkedybde:	12.7 mm
Pakkehøyde:	152.4 mm
Pakkebredde:	101.6 mm
Støttede grafikkoppløsninger:	3840 x 2160
Støttede videofunksjoner:	1080p
Bærekraftsertifikater:	RoHS
Plugg inn og spill:	Ja
Kontaktplettering:	Gull
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332198621
Masterkassens (ytterkassens) bruttovekt:	190 g
Masterkassens (ytterkassens) lengde:	25.4 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	348 mm
Masterkassens (ytterkassens) høyde:	398.8 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
