Quick Start Guide

DisplayPort 1.2 to VGA / DVI /

HDMI All-in-One Converter

Model: P136-06N-HDV4K6

Mini DisplayPort 1.2 to VGA /

DVI / HDMI All-in-One Converter

Models: P137-06N-HDV4K6 (White),

P137-06N-HDVK6B (Black)

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

WARRANTY REGISTRATION

to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 5 • Français 9 • Русский 13• Deutsch 17

20-10-108-9336B3-Book.indb 120-10-108-9336B3-Book.indb 1 10/8/2021 1:05:56 PM10/8/2021 1:05:56 PM

Product Features

System Requirements

•

Connect a VGA, DVI or HDMI monitor to a DisplayPort or Mini DisplayPort on

your laptop, tablet or computer

• Offers maximum ﬂexibility to connect to any available monitor

• Portable design with built-in cable is perfect for travel and stowing in your

laptop bag

•

HDMI port supports 4K UHD video resolutions up to 3840 x 2160 @ 60 Hz

as speciﬁed in HDMI 2.0

•

DVI port supports single-link video resolutions up to 1920 x 1080 (1080p)

• VGA port supports video resolutions up to 1920 x 1200, including 1080p

•

Supports up to 36-bit Deep Color (12 bits per channel) @ 1080p

or up

to 24-bit Deep Color (8 bits per channel) @ 4K/60 Hz

•

Complies with HDCP 2.2 standards to display up-to-date 4K video content

• P137 models are compatible with the Thunderbolt™ port on Mac

computers (e.g. MacBook Pro

and MacBook Air

)

• Requires no external power supply

• Source device with DisplayPort or Mini DisplayPort output

• Display device with VGA, DVI or HDMI input

Package Contents

Optional Accessories

• P136-06N-HDV4K6, P137-06N-HDV4K6 (White) or P137-06N-HDVK6B

(Black)

• Quick Start Guide

• P502-006 High-Resolution VGA Cable with RGB Coax – 6 ft. (1.8 m)

• P561-006 DVI-D Single-Link Cable – 6 ft. (1.8 m)

• P569-006-CERT Premium High-Speed HDMI Cable – 6 ft. (1.8 m)

20-10-108-9336B3-Book.indb 220-10-108-9336B3-Book.indb 2 10/8/2021 1:05:56 PM10/8/2021 1:05:56 PM

Speciﬁcations

Input Signal DisplayPort 1.2 or Mini DisplayPort 1.2

Output Signal VGA, DVI and HDMI

Vertical Frequency Range 50/60 Hz

Maximum HDMI Resolution 3840 x 2160 @ 60 Hz (4K x 2K)

Maximum DVI Resolution 1920 x 1080 (1080p)

Maximum VGA Resolution 1920 x 1200, including 1080p

Maximum Cable Length 6 ft. (1.8 m) for DVI and HDMI

10 ft. (3 m) for VGA

Operating Temperature 32 to 113 °F (0 to 45 °C)

Operating Humidity 10% to 85% RH, Non-Condensing

Storage Temperature 14 to 158 °F (-10 to 70 °C)

Storage Humidity 5% to 90% RH, Non-Condensing

Maximum Power Consumption 400mA

Installation

Notes:

• Only one monitor can be connected at a time.

• To connect a Mac to an HDMI monitor with audio, go to “System Preferences” and

select “Sound”. Then click the “Output” tab and select your HDMI device from the

list. Note: DisplayPort or Mini DisplayPort audio is available on all Mac models

introduced after April 2010.

• When connecting a DVI or HDMI monitor, the distance between the converter and

monitor must be no longer than 6 ft. (1.8 m). When connecting a VGA monitor, the

distance must be no longer than 10 ft. (3 m).

1. Connect the converter to the DisplayPort or Mini DisplayPort on your

computer or tablet.

2. Connect a monitor to the VGA, DVI or HDMI port on the converter.

20-10-108-9336B3-Book.indb 320-10-108-9336B3-Book.indb 3 10/8/2021 1:05:56 PM10/8/2021 1:05:56 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	P136-06N-HDV4K6
Vekt:	50 g
Bredde:	45.7 mm
Dybde:	86.4 mm
Høyde:	15.2 mm
Opprinnelsesland:	Vietnam
Pakkevekt:	90 g
HDCP:	Ja
Maksimal videooppløsning:	3840 x 2160 piksler
Vertsgrensesnitt:	DisplayPort
Utgangsgrensesnitt:	VGA/DVI/HDMI
Produktfarge:	Sort
Pakkedybde:	142.2 mm
Pakkehøyde:	22.9 mm
Pakkebredde:	99.1 mm
Harmonisert system (HS)-kode:	84733080
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332202748
Masterkassens (ytterkassens) bruttovekt:	950 g
Masterkassens (ytterkassens) lengde:	248.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	162.6 mm
Masterkassens (ytterkassens) høyde:	121.9 mm
Antall:	1
