Side 1/2

Quick Start Guide

Product Features

System Requirements

Package Includes

Installation

Mini DisplayPort to VGA / DVI / HDMI All-in-One Converter

Models: P137-06N-HDV, P137-06N-HDVW

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge

protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA •

www.tripplite.com/support

• Connect a VGA, DVI, or HDMI monitor to a

Mini DisplayPort on your laptop or tablet

• All-in-One converter offers maximum ﬂexibility

to connect to any available monitor

• Portable design with built-in cable is perfect

for travel and stowing in your laptop bag

• Supports computer video resolutions up to

1920 x 1200, or HD video resolutions up to

1920 x 1080 (1080p)

• Supports up to 36-bit Deep Color (12 bits per

channel)

• Compatible with the Thunderbolt port on

Mac

computers, such as the Macbook Pro

and Macbook Air

• Passive converter requires no external power

supply

• Computer or tablet with a Mini DisplayPort • Monitor with a VGA, DVI, or HDMI port

• P137-06N-HDV or P137-06N-HDVW • Quick Start Guide

Notes:

• Only one monitor can be connected at a time.

• To connect a Mac to a HDMI monitor with audio, go

to “System Preferences” and select “Sound”. Then

click the “Output” tab and select your HDMI device

from the list. Mini DisplayPort audio is available Note:

on all Mac models introduced after April 2010.

• When connecting a DVI or HDMI monitor, the distance

between the converter and monitor must be no longer

than 6 ft. (2 m). When connecting a VGA monitor, the

distance must be no longer than 10 ft. (3 m).

Optional Accessories

• P502-006 High Resolution VGA Cable with

RGB Coax – 6 ft.

• P561-006 DVI-D Single Link Cable – 6 ft.

• P568-006 High Speed HDMI Cable – 6 ft.

1. Connect the converter to the Mini DisplayPort on your computer or tablet.

2. Connect a monitor to the VGA, DVI, or HDMI port on the converter.

Este guía esta disponible en español en la página de Tripp Lite: www.tripplite.com/support

Ce guide est disponible en français sur le site Web de Tripp Lite : www.tripplite.com/support

Русскоязычная версия настоящего краткого руководства представлена на веб-сайте компании

Tripp Lite по адресу: www.tripplite.com

17-12-255-93339F-EN.indd 1 1/5/2018 12:02:41 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	P137-06N-HDV
Vekt:	50 g
Bredde:	45.7 mm
Dybde:	86.4 mm
Høyde:	15.2 mm
Maksimal oppløsning:	1920 x 1200 piksler
Opprinnelsesland:	China
Pakkevekt:	60 g
Maksimal videooppløsning:	1920 x 1200 piksler
Fargedybde:	36 bit
Vertsgrensesnitt:	Mini DisplayPort
Tilkobling 1:	mini DisplayPort
Tilkobling 2:	DVI-D/HDMI/HD15
Utgangsgrensesnitt:	VGA/DVI/HDMI
Kabellengde:	0.15 m
Produktfarge:	Sort
Pakkedybde:	12.7 mm
Pakkehøyde:	228.6 mm
Pakkebredde:	177.8 mm
Støttede videofunksjoner:	1080p
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84733080
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332185409
Masterkassens (ytterkassens) bruttovekt:	3900 g
Masterkassens (ytterkassens) lengde:	320 mm
Produkter per masterkasse (ytterkasse):	50 stykker
Masterkassens (ytterkassens) bredde:	520.7 mm
Masterkassens (ytterkassens) høyde:	241.3 mm
Omformertype:	Passiv
