Side 1/8

Owner’s Manual

HDMI 4K x 2K UHD Upscaler

Model: P142-06N-SC4K

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

16-04-207-9335C7-EN.indd 1 5/9/2016 9:37:24 AM

Product Features

Package Includes

Optional Accessories

• Upscales a 1080p signal @ 24 Hz to 3840 x 2160 (4K x 2K) @ 24 Hz

• Also upscales 480p and 720p signals to 1080p

• Included USB Micro-B cable supplies power to the unit

• 3D and HDCP compliant

• Plug and play—no software, drivers or external power supply required

• P142-06N-SC4K

• USB Micro-B Cable, 3 ft.

• Owner’s Manual

• P568-Series High-Speed HDMI Cables

• UR05C-Series USB Micro-B Charge-Only Cables

• U280-002-W12 2-Port USB Wall Charger

• UAC-1B 1-Port USB Wall Charger

System Requirements

• Computer, Blu-ray™ player or other source with an HDMI output port

• Monitor, television or other 4K-compliant display with an HDMI input port

16-04-207-9335C7-EN.indd 2 5/9/2016 9:37:24 AM

Installation

1. Before installation, be sure your HDMI source’s refresh rate is 24 Hz.

You can do this by accessing the settings in the menu of your Blu-ray

player or other HDMI source. Be sure the settings for 24p Output and

1080p Resolution are turned on.

Note: The 4K upscale feature will not work if your HDMI source’s refresh rate is 60 Hz.

2. Before installation, be sure the power to all devices you are connecting

to this unit is turned off.

3. Connect the HDMI source to the unit’s HDMI input port using an HDMI

cable, such as Tripp Lite’s P568-Series (see ). Optional Accessories

Note: The cable connecting the source to the unit must be no longer than 16 feet.

4. Connect the unit’s USB Micro-B port to a USB port on the display or a

USB wall charger using the included USB Micro-B cable.

5. Connect the unit’s built-in HDMI cable to the display’s HDMI input port.

Troubleshooting

If you are unable to get an acceptable image after following the installation

instructions above, try the following troubleshooting tips.

1. Is the USB Micro-B cable connected and plugged into a working

power source?

The unit must be connected to and receiving power from the USB

Micro-B cable in order to function properly.

2. Was the power to the source turned off before installation?

If not, restart your computer, Blu-ray player or other HDMI source.

3. What resolution are you trying to reach?

See the and sections for details on Product Features Installation

maximum distance and resolution. The shorter the distance, the higher

the resolution you will be able to obtain. If you are unable to get an

acceptable range, try lowering your display’s video resolution or adjusting

the refresh rate.

16-04-207-9335C7-EN.indd 3 5/9/2016 9:37:24 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	kabler for datamaskiner og annet
Modell:	P142-06N-SC4K
Opprinnelsesland:	Taiwan
Pakkevekt:	140 g
Sertifisering:	TAA
HDCP:	Ja
Antall per pakke:	1 stykker
Tilkobling 1:	HDMI
Tilkobling 2:	HDMI
Produktfarge:	Sort
Pakkedybde:	152.4 mm
Pakkehøyde:	25.4 mm
Pakkebredde:	116.8 mm
Støttede grafikkoppløsninger:	3840 x 2160
Støttede videofunksjoner:	480p, 720p, 1080p
Bærekraftsertifikater:	RoHS
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332196573
Masterkassens (ytterkassens) bruttovekt:	1330 g
Masterkassens (ytterkassens) lengde:	163.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	342.9 mm
Masterkassens (ytterkassens) høyde:	135.9 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
