Quick Start Guide

Industrial Connectivity

Solutions

Model Series: N206-XXX-IND, P569-XXX-IND, U325-XXX-IND,

N200P-XXX-IND, N455-XXX-IND, N820-XXX-IND

See page 2 for a complete model listing.

Tripp Lite’s industrial connectivity solutions comply with the IP44 standard for protection

against water intrusion on all sides, as well the IP68 standard for protection against

invasive dust, dirt and sand, and submersion in up to 1.5 m of water for up to 60 minutes.

Note: Certain product combinations are needed to achieve IP44 and/or IP68 standards.

See section 4. Product Combinations for IP44 and IP68 Protection for more information.

IP68 Protection rating is based on manufacturer’s guarantee.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 13 • Français 25 • Русский 37

Table of Contents

Industrial Connectivity Solutions Complete Product Listing 3

1. N206-SB01-IND Surface Box Dimensions 4

2. Industrial Bulkhead Coupler Installation 5

(N206-BC01-IND, U325-000-IND, P569-000-FF-IND,

N455-BC01-IND)

3. Industrial Keystone Jack Installation (N206-KJ01-IND) 7

4. Product Combinations for IP44 and IP68 Protection 10

Warranty and Product Registration 11

Industrial Connectivity Solutions

Complete Product Listing

Industrial Faceplates

N206-FP01-IND (1 Cutout)

N206-FP02-IND (2 Cutouts)

N206-FP04-IND (4 Cutouts)

Industrial Surface Mount Box

N206-SB01-IND

Bulkhead Couplers and

Keystone Jacks

N206-BC01-IND

(Cat5e/6 Bulkhead Coupler)

N206-KJ01-IND (Keystone Jack)

U325-000-IND (USB 3.0 Coupler)

P569-000-FF-IND (4K HDMI Coupler)

N455-BC01-IND

(Multimode Fiber LC/LC Coupler)

Industrial Patch Cables &

4PPoE (90W) Cables

N206-PC03-IND

(3 ft. Cat5e/6 Patch Cable)

N206-PC10-IND

(10 ft. Cat5e/6 Patch Cable)

N206-PC16-IND

(16 ft. Cat5e/6 Patch Cable)

N206-PC23-IND

(23 ft. Cat5e/6 Patch Cable)

N206-PC33-IND

(33 ft. Cat5e/6 Patch Cable)

N206-PC5O-IND

(50 ft. Cat5e/6 Patch Cable)

N200P-003BL-IND

(3 ft. Cat6 4PPoE Cables)

N200P-010BL-IND

(10 ft. Cat6 4PPoE Cables)

N200P-016BL-IND

(16 ft. Cat6 4PPoE Cables)

N200P-023BL-IND

(23 ft. Cat6 4PPoE Cables)

N200P-033BL-IND

(33 ft. Cat6 4PPoE Cables)

Industrial Patch Cables &

4PPoE (90W) Cables (continued)

N200P-050BL-IND

(50 ft. Cat6 4PPoE Cables)

Industrial USB 3.0 Cables

U325-003-IND (3 ft. USB 3.0 Cable)

U325-006-IND (6 ft. USB 3.0 Cable)

U325-01O-IND (10 ft. USB 3.0 Cable)

U325-013-IND (13 ft. USB 3.0 Cable)

Industrial 4K HDMI Cables

P569-003-IND (3 ft. 4K HDMI Cable,

1 water-resistant connector)

P569-006-IND (6 ft. 4K HDMI Cable,

1 water-resistant connector)

P569-010-IND (10 ft. 4K HDMI Cable,

1 water-resistant connector)

P569-012-IND (12 ft. 4K HDMI Cable,

1 water-resistant connector)

P569-003-IND2 (3 ft. 4K HDMI Cable,

2 water-resistant connectors)

P569-006-IND2 (6 ft. 4K HDMI Cable,

2 water-resistant connectors)

P569-010-IND2 (10 ft. 4K HDMI

Cable, 2 water-resistant connectors)

P569-012-IND2 (12 ft. 4K HDMI

Cable, 2 water-resistant connectors)

Industrial Duplex Multimode

Fiber Patch Cables

N820-01M-IND

(1 m LC/LC Fiber Patch Cables)

N820-02M-IND

(2 m LC/LC Fiber Patch Cables)

N820-05M-IND

(5 m LC/LC Fiber Patch Cables)

N820-10M-IND

(10 m LC/LC Fiber Patch Cables)

Waterproof Cable Assembly Kit

N206-WK01-IND

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	P569-006-IND2
Vekt:	190 g
Bredde:	177.8 mm
Dybde:	247.6 mm
Høyde:	31.8 mm
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	China
Pakkevekt:	190 g
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
HDMI-versjon:	2.0
Audio Return Channel (ARC):	Ja
Tilkobling 1:	HDMI Type A (Standard)
Tilkobling 2:	HDMI Type A (Standard)
Kabelhylsemateriale:	Polyvinylklorid (PVC)
Kabellengde:	1.83 m
Produktfarge:	Sort
Pakkedybde:	247.6 mm
Pakkehøyde:	31.8 mm
Pakkebredde:	177.8 mm
Driftstemperatur (T-T):	-10 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8544.42.2000
Kabeldiameter:	7.3 mm
Relativ luftfuktighet under drift (H-H):	0 - 90
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332238495
Masterkassens (ytterkassens) bruttovekt:	1910 g
Masterkassens (ytterkassens) lengde:	495.3 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	469.9 mm
Masterkassens (ytterkassens) høyde:	76.2 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hankjønn
Tilkobling 1 formfaktor:	Rett
Tilkobling 2 formfaktor:	Rett
AWG-ledningsstørrelse:	28
HDMI ethernetkanal:	Ja
