Side 1/28

Owner’s Manual

Switched Rack PDU

Zero U (Vertical) Format

Important Safety Instructions 2

Installation 2

Features 6

Technical Support 8

1111 W. 35th Street • Chicago, IL 60609 USA

www.tripplite.com/support

Configuration and Operation 8

Warranty and Warranty Registration 9

Español 10

Français 19

Warranty

Registration

chance to win a FREE Tripp Lite

product! www.tripplite.com/warranty

200912032 93-2721.indd 1 12/17/2009 11:03:08 AM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be

followed during the installation, operation, and storage of this product.

Failure to heed these instructions and warnings will void the product

warranty.

Important Safety Instructions

Installation

• The PDU provides convenient multiple outlets, but it DOES NOT provide surge or line noise

protection for connected equipment.

• The PDU is designed for indoor use only in a controlled environment away from excess moisture,

temperature extremes, conductive contaminants, dust or direct sunlight.

• Do not connect the PDU to an ungrounded outlet or to extension cords or adapters that eliminate

the connection to ground.

• The power requirement for each piece of equipment connected to the PDU must not exceed the

individual outlet’s load rating.

• The total power requirement for equipment connected to the PDU must not exceed the maximum

load rating for the PDU.

• Do not drill into or attempt to open any part of the PDU housing. There are no user-serviceable

parts inside.

• Do not attempt to modify the PDU, including the input plugs and power cables.

• Do not attempt to use the PDU if any part of it becomes damaged.

• Do not attempt to mount the PDU to an insecure or unstable surface.

• Never attempt to install electrical equipment during a thunderstorm.

• Use of this equipment in life support applications where failure of this equipment can reasonably

be expected to cause the failure of the life support equipment or to significantly affect its safety or

effectiveness is not recommended. Do not use this equipment in the presence of a flammable

anesthetic mixture with air, oxygen or nitrous oxide.

Mounting the PDU

Note: The illustrations may differ somewhat from your PDU model. Regardless of configuration, the user must determine the fitness of

hardware and procedures before mounting. The PDU and included hardware are designed for common rack and rack enclosure types

and may not be appropriate for all applications. Exact mounting configurations may vary. Screws for attaching the mounting brackets

and cord retention shelf to the PDU are included. Use only the screws supplied by the manufacturer, or their exact equivalent (#6-32,

¼" flat head).

1-1 Attach the mounting brackets to the PDU.

1-2 (Optional) Attach the cord retention

bracket(s) to the PDU.

1-3 Attach the PDU to a vertical rail in your

rack or rack enclosure. (Use the mounting

hardware that came with your rack or rack

enclosure to attach the mounting brackets to

the rail.)

1-1 1-2 1-3

200912032 93-2721.indd 2 12/17/2009 11:03:10 AM

Connecting the PDU

2-1 (Models with IEC power inlet or 3-pole

IEC 309 plug only.) Select models have a

detachable power cord. Attach the included

power cord to the PDU by inserting the IEC

connector

of the power cord into the IEC

power inlet

located near the end of the PDU.

Use the included bracket

to secure the power

cord connection.

Note: Optionally, a user-supplied power cord can be attached

to the PDU by connecting it to the IEC inlet. Do not attempt to

attach a user-supplied power cord unless it is certified to be

compatible with the input power source that will be used by the

PDU.

2-2 (Optional - models with input plug adapter

only.) Select models include an input plug

adapter that converts the twist-lock input plug

to a straight-blade input plug. Attach the input

plug adapter

to the input plug

if you wish

to plug the PDU into a compatible straight-

blade outlet.

2-3 Connect the input plug to a compatible AC

power outlet. If the PDU does not have a circuit

breaker, it should be provided with a branch-

rated over-current protection device that

matches the rated amperage of the PDU.

Note: The AC power source should not share a circuit with a

heavy electrical load.

2-4 Connect your equipment's input plugs

to the outlets

of the PDU. The LED

near

each outlet illuminates when the outlet is ready

to distribute live AC power. The digital load

meter

displays the total connected equipment

load in amps. (Select models provide additional

load data. See the Features section for more

information.)

Note: In order to minimize interference among connected

devices, connect each device to the nearest PDU outlet and coil

excess power cord length.

2-5 (Optional) If you attached the cord

retention bracket(s), tie each equipment power

cord to the retention bracket. Attach each cord

to the retention shelf by looping the cord and

securing it with one of the included cable ties

. Make sure that each cord can be unplugged

from the PDU without removing the cable tie.

Installation continued

2-1

2-2

2-3

2-4

2-5

200912032 93-2721.indd 3 12/17/2009 11:03:11 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	PDUMH20HVAT
Vekt:	4690 g
Bredde:	440.2 mm
Dybde:	375.2 mm
Høyde:	43.7 mm
LED-indikatorer:	Ja
Opprinnelsesland:	Taiwan
Pakkevekt:	8070 g
Sertifisering:	UL 60950 (USA, Canada), CE (Europe), Class A (Emissions), NOM (Mexico)
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	3.6 m
Produktfarge:	Sort
Pakkedybde:	589.3 mm
Pakkehøyde:	137.2 mm
Pakkebredde:	528.3 mm
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Kroppsmateriale:	Metall
Montering:	Horisontal
Driftshøyde:	0 - 3000 m
Rack-kapasitet:	1U
Antall AC outlets:	10 AC-utganger
Produkter per masterkasse (ytterkasse):	1 stykker
Strøm (maks.):	20 A
AC-utgangstyper:	C13 coupler, C19 coupler
Strømuttak:	C20 kopling
Nominell innputspenning:	200-240 V
PDU types:	Målte
Nominell outputspenning:	200-240 V
