Side 1/36

Owner’s Manual

Single Phase Metered 0U

Power Distribution Unit

(Bank Measurements)

200/240V MODELS

Important Safety Instructions 2

Installation 3

Features 5

Service 6

Warranty and Product Registration 7

Español 8

Français 15

Русский 22

Deutsch 29

TrippLite.Eaton.com/support

PDUMV30HV2

(Series Number: AG-013F)

PDUMV32HV

(Series Number: AG-0140)

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during

the installation, operation, and storage of this product. Failure to heed these

instructions and warnings may affect the product warranty.

CAUTION Only those who are properly trained or qualified to use this device should

do so. Anyone who is not trained or qualified should not use this device unless it is under the

supervision of someone who is properly trained or qualified to do so.

Children must be supervised to ensure that they do not use the device as a toy.

Never use the device if the cord and plug are damaged; if it is not working properly,

or if it has been dropped or damaged, take it to an authorized service center for inspection

and repair.

If the power cord is damaged, it must be replaced by the manufacturer, its authorized service

agent, or by qualified personnel in order to avoid a danger.

• The PDU provides the convenience of multiple outlets, but DOES NOT provide surge or line noise

protection for connected equipment.

• The PDU is designed for indoor use only, in a controlled environment, away from excess

moisture, temperature extremes, conductive contaminants, dust or direct sunlight.

• Keep indoor ambient temperature between 32°F and 122°F (0°C and 50°C).

• ThePDUmustbeinstalledbyaqualiedtechnicianonly.

• Do not attempt to mount the PDU to an insecure or unstable surface.

• Install in accordance with National Electrical Code standards. Be sure to use the proper

overcurrent protection for the installation, in accordance with the plug/equipment rating.

• Connect the PDU to an outlet that is in accordance with your local building codes and that is

adequately protected against excess currents, short circuits and earth faults.

• The electrical outlets supplying power to the equipment should be installed near the equipment

and easily accessible.

• Do not connect the PDU to an ungrounded outlet or to extension cords or adapters that

eliminate the connection to ground.

• Be sure to provide a local disconnect device on any models that are permanently installed

without a plug that is easily accessible.

• Never attempt to install electrical equipment during a thunderstorm.

• Individual equipment connected to the PDU should not draw more current than the individual

PDU’s outlet’s rating.

• The total load connected to the PDU must not exceed the maximum load rating for the PDU.

• Do not attempt to modify the PDU, input plugs or power cables.

• Do not drill into or attempt to open any part of the PDU housing. There are no user-serviceable

parts inside.

• Do not attempt to use the PDU if any part of it becomes damaged.

• Use of this equipment in life support applications where failure of this equipment can

reasonablybeexpectedtocausethefailureofthelifesupportequipmentortosignicantly

affect its safety or effectiveness is not recommended. Do not use this equipment in the

presenceofaammableanestheticmixturewithair,oxygenornitrousoxide.

1-5

1-1

1-6

1-5

1-2 1-3 1-4

Installation

Mounting the PDU

Note: The illustrations may differ somewhat from your PDU model. Regardless of conguration, the user must

determine the tness of hardware and procedures before mounting. The PDU and included hardware are designed

for common rack and rack enclosure types and may not be appropriate for all applications. Exact mounting

congurations may vary. Screws for attaching the mounting brackets to the PDU are included. Use only the screws

supplied by the manufacturer or their exact equivalent.

Note: Mounting buttons come preinstalled to the PDU for toolless mounting.

1-1

To mount the PDU using the pre-installed

mounting buttons, position the PDU as

desired in the rack enclosure, align the

buttons with the rack mounting slots, and

slide the PDU into position.

1-2

To attach the mounting brackets to the

PDU, remove the mounting buttons.

1-3

Attach the mounting brackets to the PDU

with the included screws.

1-4

Attach the PDU to a vertical rail in

your rack or rack enclosure. (Use the

mounting hardware that came with your

rack or rack enclosure to attach the

mounting brackets to the rail.)

1-5

To reinstall the mounting buttons for

toolless mounting, remove the mounting

brackets then install the mounting

buttons onto the PDU.

Note: Be sure to insert the 2 buttons into either

the upper hole at each end of the PDU or into

the lower hole at each end of the PDU.

1-6

To install the PDU with its outlets facing

the rear of the rack, use the included

PDUMVROTATEBRKT accessory. First,

attach the mounting button

to the

V-shaped bracket

using the included

screw and washer. Then, use the

button-mount slot to attach the bracket

to the PDU and the mounting button to

attach the PDU to the rack. The bracket

effectively repositions the mounting

brackets allowing for the PDU outlets to

face the rear of the rack.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	PDUMV32HV
Vekt:	5900 g
Bredde:	55.1 mm
Dybde:	64 mm
Høyde:	1778 mm
Opprinnelsesland:	Taiwan
Pakkevekt:	7980 g
Produktfarge:	Sort
Pakkedybde:	1927.1 mm
Pakkehøyde:	175 mm
Pakkebredde:	245.1 mm
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Kroppsmateriale:	Metall
Montering:	Vertikal
Driftshøyde:	0 - 3000 m
Rack-kapasitet:	0U
Relativ luftfuktighet under drift (H-H):	5 - 95
Antall AC outlets:	48 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332182811
Produkter per masterkasse (ytterkasse):	1 stykker
Strøm (maks.):	32 A
AC-utgangstyper:	C13 coupler, C19 coupler
Strømuttak:	IEC309
Nominell innputspenning:	230 V
PDU types:	Målte
Nominell outputspenning:	200-240 V
