Side 1/68

Owner’s Manual

Tripp Lite

DC-to-AC Inverters

Models: PINV750, PINV1000

Input: 12V DC Output: 120V 60Hz AC

Español 23 • Français 45

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

18-06-149-93385F.indb 1 7/16/2018 3:50:23 PM

Congratulations! You’ve purchased a high-quality inverter designed to

function as a mobile energy source powered by your automotive bat-

tery. Tripp Lite inverters convert 12V DC (battery) power into 120V AC

(household) power, allowing you to use equipment you commonly use

at home—computers, appliances, electronics, power tools and more—

while traveling by automobile or working at remote locations that lack

AC power. Tripp Lite inverters include advanced features that protect

your equipment, lengthen the service life of your battery and ensure

you’ll always have battery power to start your vehicle:

• Automatic Overload Protection

• Automatic Low-Battery Protection

• High-Performance DC-to-AC Inversion

• Frequency-Controlled Output Power

• Simple, Maintenance-Free Operation

• 2 AC Outlets

• 1 USB 5V 2.0A Charging Port

Important Safety Instructions 3

Feature Identiﬁcation 6

Battery Selection 9

Mounting 10

Battery Connection 13

Operation 16

Troubleshooting /Maintenance 18

Service 21

Warranty & Product Registration 22

Reliable AC Power Wherever You Need It

18-06-149-93385F.indb 2 7/16/2018 3:50:23 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS!

This manual contains important instructions and warnings

that should be followed during the installation, operation and

storage of all Tripp Lite Inverters.

Location Warnings

• Install your Inverter (whether for a mobile or stationary application)

in a location or compartment that minimizes exposure to heat, dust,

direct sunlight and moisture.

• Although your Inverter is moisture resistant, it is NOT waterproof.

Flooding the unit with water will cause it to short circuit and could

cause personal injury due to electric shock. Never immerse the

unit, and avoid any area where standing water might accumulate.

Mounting should be in the driest location available.

• Leave a minimum of 2 inches (5 cm) clearance at front and back of

the Inverter for proper ventilation. The heavier the load of connected

equipment, the more heat will be generated by the unit. Any

compartment that contains the Inverter must be properly ventilated

with adequate outside airﬂow to avoid overheating the Inverter.

• Do not install the Inverter directly near magnetic storage media, as

this may result in data corruption.

• Do not install near ﬂammable materials, fuel or chemicals.

• Do not mount unit with its front or rear panel facing down (at any

angle). Mounting in this manner will seriously inhibit the unit’s

internal cooling, eventually causing product damage not covered

under warranty.

18-06-149-93385F.indb 3 7/16/2018 3:50:23 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteri
Modell:	PINV1000
Vekt:	1220 g
Bredde:	128 mm
Dybde:	184.9 mm
Høyde:	76.2 mm
Opprinnelsesland:	China
Pakkevekt:	1780 g
Antall per pakke:	1 stykker
Inngangsspenning:	12 V
Utgangseffekt:	1000 W
Utgangsstrøm:	120 V
Kabellengde:	0.91 m
Produktfarge:	Black, Blue
Antall USB-porter:	1
Type strømforsyning:	Automatisk/innendørs
Pakkedybde:	117.3 mm
Pakkehøyde:	254.8 mm
Pakkebredde:	193.8 mm
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8504.40.9570
Strømtype:	DC-to-AC
Inngangsfrekvens:	60 Hz
Kroppsmateriale:	Aluminium
Strømbeskyttelsesfunksjoner:	Overbelastning
Relativ luftfuktighet under drift (H-H):	0 - 95
Formål:	Universell
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332225167
Masterkassens (ytterkassens) bruttovekt:	12000 g
Masterkassens (ytterkassens) lengde:	385.1 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	279.9 mm
Masterkassens (ytterkassens) høyde:	415 mm
Justerbar utgangs-spenning:	Ja
