Side 1/20
1
Copyright © 2000 Tripp Lite. All rights reserved. PowerVerter
®
is a registered trademark of Tripp Lite.
1111 W. 35th Street
Chicago, IL 60609 USA
Customer Support: (773) 869-1234
www.tripplite.com
Owner's Manual
PV 500FC PV 2000FC
PV 1000FC PV 2400FC
PowerVerter Plus
®
120V, 60 Hz Output
DC-to-AC Power Inverters
• Voltage- and Frequency-Controlled
• High Peak Power, High Efficiency
Español: p. 9
Installation: p. 3 - 5
Service & Warranty: p. 8
Safety: p. 2
Operation & Features: p. 6 - 7
Specifications: p. 8
Diagrams: p. 17 - 20
Your PowerVerter Plus converts DC power from connected batteries into AC power for
connected equipment. It can provide up to twice its continuous output rating for short periods,
enabling it to run electrical devices such as motors that have a high power demand at startup.
Read this manual carefully to learn how to connect, operate and maintain your PowerVerter Plus.
200002001 CURRENT PV 500-2400FC.p65 4/12/00, 1:44 PM1
2
Safety
This manual contains important instructions and warnings that should be followed during the
installation, operation and storage of all Tripp Lite PowerVerter Systems.
PowerVerter Location Warnings
• Install your PowerVerter indoors, away from excess moisture or heat, dust or direct
sunlight.
• Do not attempt to mount your PowerVerter on a vertical surface.
• Leave adequate space around all sides of the PowerVerter for proper ventilation. The
more power connected equipment draws, the more heat will be generated by the
PowerVerter.
• Do not install the PowerVerter near magnetic data storage media, as this may result in
data corruption.
Battery Connection Warnings
• Your PowerVerter will not operate until batteries are connected.
• Multiple battery systems must be made up of batteries of the same voltage, age, amp
hour capacity and type.
• Keep battery location well ventilated. Explosive hydrogen gas can accumulate near
batteries if they are not kept well ventilated.
• Sparks may result during final battery connection. Always observe proper polarity as
batteries are connected.
• Tighten your battery terminals to create an efficient battery connection and prevent
excessive heating.
• Do not allow objects to contact the two DC input terminals. Do not short or bridge these
terminals together. Serious injury to property or person could result.
Equipment Connection Warnings
• Do not use Tripp Lite PowerVerter Systems in life support applications where a
malfunction or failure of a Tripp Lite PowerVerter System could cause failure or
significantly alter the performance of a life support device.
• Do not connect a surge suppressor, line conditioner or UPS to the output of the
PowerVerter.
Operation Warnings
• Your PowerVerter does not require routine maintenance. Do not open your PowerVerter
for any reason. There are no user-serviceable parts inside.
• Potentially lethal voltages exist within this unit as long as the batteries are connected.
During any service work, the batteries should therefore be disconnected.
• Do not connect or disconnect batteries while the PowerVerter is operating. Dangerous
arcing may result.
200002001 CURRENT PV 500-2400FC.p65 4/12/00, 1:44 PM2
3
Installation Overview
1) Mount PowerVerter (
Mounting
, p. 3)
2) Select Battery(ies) (
Battery Selection
, p. 4)
3) Connect Battery(ies) (
Battery Connection
, p. 5)
4) Connect Equipment (
Outlets
, p. 6)
5) Turn PowerVerter On (
Power Switches
, p. 6)
Mounting (Optional*)
*Recommended for all Vehicular and Marine Applications
Due to their size and weight, the PowerVerter Plus systems in this manual should be mounted directly
to a rigid horizontal surface, mounting plate or bracket before battery connection. User must supply
all fasteners and brackets. Turn your PowerVerter and connected equipment OFF before mounting.
Mounting for the PV 500FC or PV 1000FC (See Diagram 1, p. 17)
• Install four 5mm (#8) fasteners (A) into a rigid horizontal surface using the measurements
in the diagram. Leave the heads of the fasteners raised slightly above the surface in order
to engage the keyhole slots molded into the bottom of the PowerVerter's feet.
• Place keyhole slots in the PowerVerter's four feet over the four fasteners and slide the
PowerVerter forward or backward to secure it. Install an "L"-shaped brackets (B) as shown
to permanently hold the PowerVerter in position.
Mounting for the PV 2000FC or 2400FC (See Diagram 2, p. 17)
• Install two 8 mm (1/4 in.) fasteners (A) into a rigid
horizontal
surface using the measurements
in the diagram. (Leave the heads of fasteners raised slightly above the horizontal surface
in order to engage the slots in the PowerVerter's two front feet.)
• Slide PowerVerter forward to fully engage the fasteners in the PowerVerter's front feet. Install
two 8 mm (1/4 in.) fasteners (B) into the horizontal surface, through the slots in the Power-
Verter's two rear feet. Tighten the screws to permanently hold your PowerVerter in position.
Splash Guard (PV 500FC and PV 1000FC Models Only)
(Optional; Recommended for all Marine Applications)
When adding a splash guard to a PowerVerter for use in a damp environment, spacers must be
used to maintain a proper ventilation for the inverter. User must supply splash guard, screws and
spacers. Turn your PowerVerter and connected equipment OFF before mounting.
Adding a Splash Guard for the PV 500FC or PV 1000FC (See Diagram 3, p. 17)
•Thread four 4mm (#8) sheet metal screws (A) through four holes in a rigid horizontal splash
guard (B) measuring 175 mm x 225 mm, through four 25mm long hollow spacers (C) and
into the four blind holes in the top panel of your PowerVerter.
200002001 CURRENT PV 500-2400FC.p65 4/12/00, 1:44 PM3
