Side 1/12

Protect It!

Surge Protector with

Dedicated USB Charging Ports

Model: TLP26USBB

1111 W. 35th Street Chicago, IL 60609 USA • www.tripplite.com/support

is a registered trademark of Tripp Lite.

Owner’s Manual

Important Safety Instructions 2

Product Description 2

Product Features 2

Installation 3

Lifetime Limited Warranty 3

Warranty Registration 3

Ultimate Lifetime Insurance Policy 4

Español 5

Français 8

14-03-275-93334C.indb 1 4/29/2014 5:42:02 PM

SAVE THESE INSTRUCTIONS

CAUTION! DO NOT connect to an ungrounded outlet. DO NOT use with 2-wire extension cords

or adapters. This surge protector is designed for indoor use only. Install the surge protector away

from heat-emitting appliances such as radiators or heat registers. Do not install where excessive

moisture is present. Do not plug extension cords into it. Never install electrical, telephone,

network or coaxial wiring during a lightning storm. Do not drill into any part of the housing or

open the housing for any reason. There are no user-serviceable parts inside.

Important Safety Instructions

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to significantly

affect its safety or effectiveness is not recommended. Do not use this equipment in the

presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

Product Description

Product Features

The TLP26USBB Protect It!

Desktop Surge Protector includes two unswitched power receptacles

and four USB charging ports in a small, compact design. A built-in cradle provides upright

support to a tablet or smartphone while it charges for convenient access.

LED Indicators: GROUNDED illuminates red when the unit is connected to a properly

grounded outlet. PROTECTED illuminates green when the unit is actively protecting

connected components from transient surges.

NEMA 5-15R Outlets: Two unswitched outlets provide power and surge protection to

devices with conventional power plugs.

USB Charger Ports: Four USB ports are arranged in two sets of two. Each set of ports is

capable of providing 2.4 amps of charging power to tablets, smartphones, MP3 players and

other personal electronic devices.

Device Cradle: A recessed cradle section allows for convenient tablet or smartphone

placement within the unit while it is connected to a USB Charger Port.

Top of Unit Side of Unit

14-03-275-93334C.indb 2 4/29/2014 5:42:04 PM

Installation

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and

workmanship for its lifetime. If the product should prove defective in material or workmanship within that period, Seller will repair

or replace the product, in its sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the

product (with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th St., Chicago, IL 60609. Seller will pay return

shipping charges.

The warranties of all TRIPP LITE surge protectors are null and void if they have been connected to the output of any UPS system.

The warranties of all TRIPP LITE UPS Systems are null and void if a surge protector has been connected to its output receptacles.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR

NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO

THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY

OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY

EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied

warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above

limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may have other rights which

vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the

use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty

as to the suitability or fitness of these devices for any specific application.

The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.

Regulatory Compliance Identification Numbers

For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique

series number. The series number can be found on the product nameplate label, along with all required approval markings and

information. When requesting compliance information for this product, always refer to the series number. The series number

should not be confused with the marketing name or model number of the product.

Lifetime Limited Warranty

Warranty Registration

Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You'll be automatically entered into

a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Connect Your Surge Protector to the AC Power Line: Plug the surge protector’s power cord

into a standard, 3-wire grounded 120V AC outlet.

Check Your Surge Protector’s Diagnostic Indicator Lights Prior to Connecting Equipment:

The diagnostic LEDs will indicate various operating conditions when the surge protector is

plugged into a live 120V AC outlet.

“PROTECTED” LED: Indicates the surge suppression components are intact and providing

complete protection against surges. If this LED does not illuminate, some of the surge

suppression components are not functioning, and the unit should be replaced.

Visit www.tripplite.com/support.

“GROUNDED” LED: Indicates wall outlet is grounded and surge protection can properly

function. If this light DOES NOT illuminate and power is present, consult a qualified

electrician to examine your outlet’s wiring.

Connect Your Equipment to the Surge Protector’s AC Outlets: Plug your equipment’s power

cords (including 2-wire devices) into the surge protector’s AC outlets. DO NOT plug in extension

cords. DO NOT OVERLOAD the surge protector’s outlets. The surge protector can accommodate

a total equipment load of up to 15 amps (whether plugged into a single outlet or spread out

over both outlets).

14-03-275-93334C.indb 3 4/29/2014 5:42:04 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	Protect It! TLP26USBB
Vekt:	540 g
Bredde:	132.3 mm
Dybde:	132.3 mm
Høyde:	36.1 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	730 g
Sertifisering:	UL60905, cUL
Materiale:	Plast
Kabellengde:	1.83 m
Produktfarge:	Sort
Antall USB-porter:	4
Pakkedybde:	147.3 mm
Pakkehøyde:	91.4 mm
Pakkebredde:	165.1 mm
Bærekraftsertifikater:	RoHS
Rack-montering:	Nei
Antall medfølgende produkter:	1 stykker
Antall AC outlets:	2 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332183382
Masterkassens (ytterkassens) bruttovekt:	4260 g
Masterkassens (ytterkassens) lengde:	284.5 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	302.3 mm
Masterkassens (ytterkassens) høyde:	177.8 mm
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA 5–15P
Nominell innputspenning:	120 V
Strømstøt energivurdering:	1080 J
EMI/RFI-lydfiltrering:	Ja
