Side 1/12
Owner’s Manual
Protect It!
®
3-Outlet
Surge Protector with
USB Charging
With Desk Clamp: TLP310USBC
With Mounting Brackets: TLP310USBS
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an
ISOBAR6ULTRA surge protector—
a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2016 Tripp Lite. All rights reserved. Protect It!
®
is a registered trademark of Tripp Lite.
Important Safety Instructions 2
Installation 2
TLP310USBC Desk Clamp Model 2
TLP310USBS Mounting Brackets Model 3
Product Registration 4
Lifetime Limited Warranty 4
Ultimate Lifetime 4
Insurance Policy
16-09-095-933637.indb 1 10/7/2016 12:15:59 PM
2
Important Safety Instructions
Installation –TLP310USBC Desk Clamp Model
SAVE THESE INSTRUCTIONS
CAUTION! DO NOT connect to an ungrounded outlet. DO NOT use with 2-wire extension cords
or adapters. This surge protector is designed for indoor use only. Install the surge protector away
from heat-emitting appliances such as radiators or heat registers. Do not install where excessive
moisture is present. Do not plug extension cords into it. Never install electrical, telephone,
network or coaxial wiring during a lightning storm. Do not drill into any part of the housing or
open the housing for any reason. There are no user-serviceable parts inside.
Use of this equipment in life support applications where failure of this equipment can reasonably
be expected to cause the failure of the life support equipment or to significantly affect its safety
or effectiveness is not recommended. Do not use this equipment in the presence of a flammable
anesthetic mixture with air, oxygen or nitrous oxide.
1
2
3
4
3-outlet surge
protector with
USB charging
Use p2-x2 pan head self-tapping
screw (m3-24%, 12 mm) to
attach the surge protector to
the clamp.
Clamp-mount
stand
16-09-095-933637.indb 2 10/7/2016 12:16:02 PM
3
Installation –TLP310USBS Mounting Brackets Model
IMPORTANT!
This unit contains two mounting hardware bags.
Use the bag as listed for the appropriate mounting installation:
Bag A – In-Desk Mounting
x2 Mounting bracket
x4 Flat head machine screw (6#32T, 1/4”)
x2
Truss head self-tapping screw (M4-16T, 14 mm)
Bag B – Under/On Desk Mounting
x2 Mounting bracket
x4 Flat head machine screw (6#32T, 1/4”)
x4
Truss head self-tapping screw (M4-16T, 14 mm)
In-Desk Mounting
Use hardware contents for this installation.Bag A
Under/On Desk Mounting
Use hardware contents for this installation.Bag B
Under Desk
or
On Desk
x4 Flat head
machine screws
(6#32T, 1/4”)
x4 Flat head
machine screws
(6#32T, 1/4”)
x4 Flat head
machine screws
(6#32T, 1/4”)
2 1/4”
(56 mm)
7 1/4” (184 mm)
x2 Truss head
self-tapping screws
(M4-16T, 14 mm)
x4 Truss head
self-tapping screws
(M4-16T, 14 mm)
x4 Truss head
self-tapping screws
(M4-16T, 14 mm)
1
1
1
2
2
2
16-09-095-933637.indb 3 10/7/2016 12:16:05 PM

Produkspesifikasjoner

Merke: Tripp Lite
Kategori: Ikke kategorisert
Modell: Protect It! TLP310USBS
Vekt: 750 g
Bredde: 183.9 mm
Dybde: 39.1 mm
Høyde: 55.9 mm
Opprinnelsesland: China
Pakkevekt: 860 g
Materiale: Plast
AC-inngangsfrekvens: 60 Hz
Klemmespenning: 1000 V
Toppstrøm, normal modus: 15 A
Kabellengde: 3.05 m
Produktfarge: Sort
Antall USB-porter: 2
Pakkedybde: 137.2 mm
Pakkehøyde: 228.6 mm
Pakkebredde: 63.5 mm
Bærekraftsertifikater: RoHS
Oppdateringsresponstid: 0.00006 ms
Antall AC outlets: 3 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC): 10037332198478
Masterkassens (ytterkassens) bruttovekt: 8800 g
Masterkassens (ytterkassens) lengde: 355.6 mm
Produkter per masterkasse (ytterkasse): 10 stykker
Masterkassens (ytterkassens) bredde: 284.5 mm
Masterkassens (ytterkassens) høyde: 233.7 mm
AC-utgangstyper: NEMA 5–15R
Strømuttak: NEMA 5–15P
Nominell innputspenning: 120 V
Strømstøt energivurdering: 510 J
