Owner’s Manual
Mounting Clamp
for Medical-Grade Power Strips
Model: PSCLAMP2
Table of Contents
1. Important Safety Instructions 2
2. Parts and Features 2
3. Installation 3
4. Lifetime Limited Warranty 4
Français 5
PROTECT YOUR INVESTMENT!
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
2
1. Important Safety Instructions
2. Parts and Features
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that must be followed during the installation of the product described in this
manual. Read instructions before attempting to install this product. Failure to comply may invalidate any warranty and ALL
cause serious property damage and/or personal injury.
The PSCLAMP2 mounting kit includes:
• 2 Mounting Brackets
• 2 Retainer Brackets
• 4 Screws
• (2) M6 12 mm Phillips Head Screws
• (4) M5 30 mm Phillips Head Screws
The PSCLAMP2 is designed to be used with Tripp Lite’s
Medical-Grade Power Strips. To accommodate a wide variety
of applications, the clamps fit tubes 7/8” – 1¼”.
Mounting Brackets Retainer Brackets
M6 12 mm Screws M5 30 mm Screws
3
3. Installation
Before beginning installation, verify that all necessary package contents are present and that the power strip to be mounted
conforms to the standards necessitated by its mounting location.
1
Secure mounting brackets
A
loosely to each end of the
power strip
B
using the two M6 screws provided.
2
Mount the power strip to the mobile cart, IV tube or
other application by using the retainer brackets and four
M5 screws provided. Tighten the mounting brackets
securely in place.
3
Tighten the M6 screws used to attach the power strip to
the mounting brackets.
1
2
B
A

Produkspesifikasjoner

Merke: Tripp Lite
Kategori: Ikke kategorisert
Modell: PSCLAMP2
Vekt: 240 g
Opprinnelsesland: China
Pakkevekt: 420 g
Sertifisering: RoHS
Materiale: Metall
Produktfarge: Hvit
Pakkedybde: 273 mm
Pakkehøyde: 77 mm
Pakkebredde: 158 mm
Harmonisert system (HS)-kode: 8302.50.0000
Skruer inkludert: Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC): 10037332225488
Masterkassens (ytterkassens) bruttovekt: 5780 g
Masterkassens (ytterkassens) lengde: 492 mm
Produkter per masterkasse (ytterkasse): 12 stykker
Masterkassens (ytterkassens) bredde: 292.1 mm
Masterkassens (ytterkassens) høyde: 335 mm
