Side 1/3

Tripp Lite has a policy of continuous improvement. Product specifications are subject to change without notice.

Note on Labeling

Two symbols are used on the label.

V~ : AC Voltage V : DC Voltage

Under normal conditions, the original battery in your UPS will last several years. Battery replacement

should be performed only by qualified service personnel. Refer to “Battery Warnings” in the Safety

section. Should your UPS require battery replacement, visit Tripp Lite on the Web at

www.tripplite.com/support/battery/index.cfm to locate the specific replacement battery for your UPS.

Battery Replacement

Carefully pull the front

panel away from the

UPS.

Place front panel on top of the unit.

Remove battery cover.

Disconnect the wiring harness connecting

the batteries to the unit. Use a screwdriver

to remove the screws holding the battery

cover to the unit and carefully remove the

cover.

Remove old battery

pack.

Carefully pull the batteries from the UPS

by using the pull tab.

Connect new batteries.

Carefully push the new battery pack

back into the UPS.

Reassemble UPS.

Reinstall the battery cover, connect the

battery wires to the UPS and install the

front panel.

Instruction Sheet

RBC48V-HGTWR

Replacement

Battery Pack

201206033-933228-EN

SmartPro

is a registered trademark of Tripp Lite.

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

4-5

WARRANTY

REGISTRATION

chance to win a FREE Tripp Lite

product! www.tripplite.com/warranty

201206033-933228.indd 1 6/21/2012 10:54:14 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteri
Modell:	RBC48V-HGTWR
Vekt:	11340 g
Bredde:	195.1 mm
Dybde:	214.9 mm
Høyde:	100.1 mm
Opprinnelsesland:	Vietnam
Pakkevekt:	11880 g
Kompatibilitet:	SMART2500XLHG
Antall battericeller:	4
Produktfarge:	Sort
Pakkedybde:	320 mm
Pakkehøyde:	165.1 mm
Pakkebredde:	249.9 mm
Batterispenning:	48 V
Bærekraftsertifikater:	RoHS
Driftshøyde:	0 - 3000 m
Masterkassens (ytterkassens) bruttovekt:	11880 g
Masterkassens (ytterkassens) lengde:	320 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	249.9 mm
Masterkassens (ytterkassens) høyde:	165.1 mm
