SmartRack

2400 Series

Enclosures

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Important Safety Instructions 2

Overview 2

Feature Identification 3

Enclosure Installation 4

Preparation 4

Unpacking 4

Placement 5

Leveling 6

Ground Connection 6

Enclosure Configuration 7

Adding or Removing Front and 7

Rear Doors

Reversing Front Door 7

Adding or Removing Roof Panel 9

Adding or Removing Side Panels 9

Adjusting Mounting Rails 10

Adjusting PDU Mounting Brackets 11

Combining (Baying) Enclosures 12

Equipment Installation 12

Installing or Removing Cage Nuts 13

Specifications 14

Storage and Service 14

Warranty and Warranty Registration 14

Español 15

Français 29

Important Safety Instructions

SAVE THESE INSTRUCTIONS

All sections of this manual contain instructions and warnings that should be followed during the installation and use of the SmartRack Enclosures described in

this manual. Read all instructions and warnings thoroughly before attempting to move, install or use the SmartRack Enclosures described in this manual.

Failure to comply will create a risk of personal injury and property damage and may invalidate the warranty.

• Keeptheenclosureinacontrolledindoorenvironment,awayfrommoisture,temperatureextremes,flammableliquidsandgasses,conductivecontaminants,

dust and direct sunlight.

• Leaveadequatespaceatthefrontandrearoftheenclosureforproperventilation.Donotblock,coverorinsertobjectsintotheexternalventilationopenings

of the enclosure.

• Theenclosureisextremelyheavy.Usecautionwhenhandlingtheenclosure.Donotattempttounpack,moveorinstallitunassisted.Useamechanical

device such as a forklift or pallet jack to move the enclosure in the shipping container.

• Donotplaceanyobjectontheenclosure,especiallycontainersofliquid,anddonotattempttostacktheenclosures.

• Inspecttheshippingcontainerandtheenclosureforshippingdamage.Donotusetheenclosureifitisdamaged.

• Leavetheenclosureintheshippingcontaineruntilithasbeenmovedasclosetothefinalinstallationlocationaspossible.Thecastersaredesignedfor

minor position adjustments within the final installation area only. The casters are not designed for moving the enclosure over longer distances.

• Thecastersarenotdesignedtoprovidelong-termsupportfortheenclosureafterfinalinstallation.Usethelevelerstoprovidelong-termsupport.

• Installtheenclosureinastructurallysoundareawithalevelfloorthatisabletobeartheweightoftheenclosure,allequipmentthatwillbeinstalledinthe

enclosureandanyotherenclosuresand/orequipmentthatwillbeinstallednearby.

• Donotpushtheenclosurefromthesidepanelstomoveit.Pushingfromthesidepanelswillcauseatippinghazard.

• Whenrollingtheenclosureonitscasters,alwayspushitfrombehind,neverpullittowardyou.

• Arollingenclosurecancausepersonalinjuryandpropertydamageifnotproperlysupervised.Ifrollingtheenclosuredownarampisrequired,useextreme

caution.Donotattempttouserampsthathaveaslopesteeperthan1:12.

• Usecautionwhencuttingpackingmaterials.Theenclosurecouldbescratched,causingdamagenotcoveredbythewarranty.

• Saveallpackingmaterialsforlateruse.Repackingandshippingtheenclosurewithouttheoriginalpackingmaterialsmaycauseproductdamagethatwillvoid

the warranty.

• Donotre-shiptheenclosurewithadditionalequipmentunlesstheenclosurewasshippedwithaspecialshockpallet(“SP1”modelsonly).Thecombined

weightoftheenclosureandinstalledequipmentmustnotexceedtheloadcapacityofthepallet.TrippLiteisnotresponsibleforanydamagethatoccurs

duringre-shipment.

• Useofthisequipmentinlifesupportapplicationswherefailureofthisequipmentcanreasonablybeexpectedtocausethefailureofthelifesupport

equipmentortosignificantlyaffectitssafetyoreffectivenessisnotrecommended.Donotusethisequipmentinthepresenceofaflammableanesthetic

mixturewithair,oxygenornitrousoxide.

Overview

SmartRackEnclosuresaccommodateallstandard19-inchrackmountequipment,regardlessofvendor,andshipfullyassembledforquickandeasydeployment.

Theyfeatureadaptable,heavy-dutycabinetsin42U,45Uand48Uheights,withorwithoutsidepanels.Severalmodelsareavailablewithanintegratedshock

palletthatallowsresellers,integratorsandenterprisecustomerstopre-configureequipmentandre-shiptheenclosurestothefinalinstallationsite.

SmartRackEnclosureshavevariablemountingdepths,idealforservers.Integratedbayinghardwareenablescost-effective,orderlyandefficientexpansion.The

cabinetsincludequick-releasedoorsandsidepanelsforconvenientmaintenanceandsplitreardoorsforimprovedaccessandreducedclearancerequirements.

Frontaccessdoorsarereversibleforinstallationflexibility.Frontandreardoorsandsidepanelsarelockable.

Feature Identification

Model SR2400 is shown. Other 2400 Series models will have similar features with any differences noted.

Roof Panel

Locking Split Rear Doors

Locking Side Panels (Sidepanelsarenotincludedwith“EXP”models.)

Cable Management Rails

Casters

and Levelers

Mounting Rails (Providehorizontalandverticalmountingpointsforequipment.)

Keys (Oneforthedoorsandoneforthesidepanels.)

Locking Reversible Front Door

Not Shown: Mounting hardware, documentation, shipping brackets and other shipping materials.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	SmartRack SR2400
Vekt:	126100 g
Bredde:	600.2 mm
Dybde:	1092.2 mm
Høyde:	1993.9 mm
Opprinnelsesland:	China
Pakkevekt:	148780 g
Sertifisering:	UL60950, RoHS, CE, EIA/ECA-310-E, NOM
Produktfarge:	Sort
Pakkedybde:	1143 mm
Pakkehøyde:	2159 mm
Pakkebredde:	660.4 mm
Harmonisert system (HS)-kode:	8517.79.0000
Modell/Type:	Frittstående hylle
Rack-kapasitet:	42U
Masterkassens (ytterkassens) bruttovekt:	148780 g
Masterkassens (ytterkassens) lengde:	1143 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	660.4 mm
Masterkassens (ytterkassens) høyde:	2159 mm
Høyde (imperial):	78.5 "
Bredde (imperial):	23.63 "
