Side 1/8
SmartRack
®
Assembly Instructions
Instrucciones de Ensamble del SmartRack®
Model/Modelo: SR42UBEVS
1111 West 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All trademarks are the sole property of their respective owners.
Copyright © 2019 Tripp Lite. Todas las marcas registradas son exclusivas de sus respectivos propietarios.
2
M6 Flange
Nut
M4 Phillips
Self Tapping Screws
M6
Flat Washer
Keys
A B C D
E F G H I J
x8 x2x16
x1 x1 x2 x2 x2x2
x16
Required Tools:
#1 Phillips Screwdriver
#2 Phillips Screwdriver
Open End Wrench or Ratchet
Optional Accessory:
SRCASTER Rolling Caster Kit
Visit www.tripplite.com/support for additional information.
WARNING: The rack enclosure is extremely heavy. Do not attempt to unpack, move, assemble or install the
enclosure without assistance. Until it has been properly assembled and stabilized, the enclosure is prone to
tipping and could cause property damage and/or personal injury. Use extreme caution when assembling the
enclosure. Tighten all fasteners securely and do not attempt to install equipment without first stabilizing the
enclosure.
Assembly instructions begin on page 4.
FRONT
REAR
NON-LOCKING LOCKING
3
Lista de Piezas
M6 Tuerca
de Brida
M4 Tornillo
Autoroscante Phillips
M6
Arandela Plana
Llaves
A B C D
E F G H I J
x8 x2x16
x2 x1 x1 x2 x2 x2
x16
Accesorio Opcional:
Juego de Ruedas SRCASTER
Para más información, visite www.tripplite.com/support.
Herramientas Necesarias:
Desatornillador Phillips #1
Desatornillador Phillips #2
Llave Española o de Trinquete
ADVERTENCIA: El gabinete es extremadamente pesado. No intente desempacar, mover, ensamblar o instalar
el gabinete sin ayuda. Una vez que esté completamente enxamblado y estabilizado, el gabinete es propenso
a volcarse y podría causar daños a la propiedad y/o lesiones personales. Tenga extreme cuidado al ensamblar
el gabinete. Apriete firmemente todos los sujetadores y no intente instalar equipo sin estabilizar primero el
gabinete.
ANTERIOR
POSTERIOR
SIN CIERRE CIERRE
