Installation Guide
Straight Channel Section for
Fiber Routing System
Models: SRFC5STR48, SRFC5STR72, SRFC10STR48, SRFC10STR72
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
Español 5 • Français 9 • Русский 13
2
Parts List
Straight Channel Section, x1
Models and Dimensions
Before proceeding with installation, first confirm your model and dimensions.
Model Cross-Sectional View Height Interior Width Length
SRFC5STR48
4.6 in.
(118 mm)
4.8 in.
(120 mm)
48 in.
(1219 mm)
SRFC5STR72
4.6 in.
(118 mm)
4.8 in.
(120 mm)
72 in.
(1829 mm)
SRFC10STR48
4.6 in.
(118 mm)
9.5 in.
(241 mm)
48 in.
(1219 mm)
SRFC10STR72
4.6 in.
(118 mm)
9.5 in.
(241 mm)
72 in.
(1829 mm)
3
Additional Accessories
All accessories are sold separately.
Accessory Model Number
Accessory Description and Function
5 in. (120 mm) System 10 in. (240 mm) System
SRFC5CPL5 SRFC10CPL10 Coupler Kit to Connect Channels and Fittings
SRFC5RAMP SRFC10RAMP Up/Down Ramp to Change Level of a Horizontal Run
SRFC5ELBOW SRFC10ELBOW 90-Degree Fitting to Create Elbow in a Horizontal Run
SRFC5JUNT SRFC10JUNT T-Shaped Fitting to Create 90-Degree Branch from a Straight Run
SRFC5JUNT4 SRFC10JUNT4 4-Way Cross Fitting to Create a Junction with 2 Horizontal Exits
SRFC5DROP SRFC10DROP
Trumpet Drop-Out Kit to Limit Bend Radius at an Exit from a
Channel, Horizontal T or Vertical T
SRFC4WTRFL
Movable Waterfall Adapter to Enable Cable to Cascade over the
Side at a Horizontal Exit
SRFC4WTRFL36
Movable Waterfall Adapter with Pipe to Enable Cable to Cascade
over the Side into 36 in. Corrugated Plastic Pipe at a Horizontal Exit
SRFC4WTRFL48
Movable Waterfall Adapter with Pipe to Enable Cable to Cascade
over the Side into 48 in. Corrugated Plastic Pipe at a Horizontal Exit
SRFC5CAP SRFC10CAP
End Cap Kit to Close off the End of a Channel for a Professional,
Finished Look
SRFC5CPL10
Adapter to Combine 5 in. (120 mm) Components with 10 in.
(240 mm) Components
