Installation Guide
Link Span Kit for
Wire Basket Cable Trays
Models:
SRWBARCBFFL, SRWBARCBFFL4
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Español 3 • Français 5 • Русский 7
2
Parts List
Assembly
1 x 4 x
90° Bends
6" (150 mm) Wire Basket Model(s): SRWB6210STR, SRWB6410STR
Wire Tray Configuration
For instructions on cutting and fabricating wire basket
trays, please refer to the documentation included
with the SRWB Wire Baskets (sold separately).
This section provides wire tray cutting patterns and configuration
instructions. For the sectional views shown for each wire tray model,
the wires in the red portions should be cut and wires in the black
portions should remain intact (see example below).
Uncut
Wires
Cut Wires
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
19-07-406 93-39DB_RevA
12" (300 mm) Wire Basket Model(s): SRWB12210STR, SRWB12410STR
18" (457 mm) Model: SRWB18410STR
SRWBARCBFFL or SRWBARCBFFL4
(For use with (For use with
2" tall wire baskets) 4" tall wire baskets)
Axis Coupler
(Model , SRWBAXISCPLR
sold separately)
Axis Coupler
(Model , SRWBAXISCPLR
sold separately)
Axis Coupler
(Model , SRWBAXISCPLR
sold separately)
Coupler
(Model , SRWBUNVCPLR
included)
Coupler
(Model , SRWBUNVCPLR
included)
Coupler
(Model , SRWBUNVCPLR
included)
SRWBUNVCPLR
Coupler
Guía de Instalación
Juego de Expansión de Enlace
para Charolas para Cableado de
Canastilla de Alambre
Modelos:
SRWBARCBFFL, SRWBARCBFFL4
1111 W. 35th Street, Chicago, IL 60609 EE. UU. • tripplite.com/support
Copyright © 2019 Tripp Lite. Todos los derechos reservados.
MÁS DE
AÑOS
English 1 • Français 5 • Русский 7
