Owner’s Manual

SmartRack

™

High-Capacity Vertical Cable Manager

Models:

SRCABLEVRT3, SRCABLEVRT6 & SRCABLEVRT12

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

Introduction

SRCABLEVRT models are high capacity cable managers for Tripp Lite open frame racks and rack enclosures. The SRCABLEVRT6

and SRCABLEVRT12 models are designed for use in either a 2-post or 4-post open frame rack, while the SRCABLEVRT3 is

designed for installation in the SR42UBWD extra-wide enclosure. Each SRCABLEVRT unit includes three cable trays along

with three adapter plates that allow the unit to be mounted to PDU managers in 42U SmartRack enclosures.

Parts List

Cable Tray

Frames (3)

Adapter Plates

(3)**

Cable Tray

Doors (3)*

Cable Tray

Door Straps

(9)**

Cable

Guides (12)

Tie Plates (2)* Mounting

Buttons (6)

‡

Mounting

Brackets (6)*

Mounting

Brackets (6)**

Door Hinges (18) M4 x 6 mm

Flat Head

Screws (12)

†

M4 x 12 mm Pan

Head Screws (18)

‡

M4 x 8 mm Pan

Head Screws (8)

Single-Depth Installation ��2

SR42UBWD Installation: Front-Facing��11

Double-Depth Installation �� 6

SR42UBWD Installation: Side-Facing��14

*SRCABLEVRT6 & SRCABLEVRT12 only.

**SRCABLEVRT3 only.

†SRCABLEVRT3 includes 6 pieces.

‡SRCABLEVRT3 includes 12 pieces.

42U Enclosure with PDU Manager Installation Side-Facing��16
