Installation Guide

LCD Panel Fixed Mount

for 19” Racks

Model: SRLCDMOUNT

Español 5 • Français 9 • Русский 13

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

75x75 / 100x100 /

100x150

17”

MAX

19”

MAX

44 lb.

(20 kg)

MAX

For INSIDE

Rack Installations

For OUTSIDE

Rack Installations

Without Doors

Important Safety Instructions

Warranty & Product Registration

NOTE: Read the entire instruction manual before you start installation and assembly.

WARNING

• Do not begin the installation until you have read and understood the instructions and warnings contained in this guide. If you have

any questions regarding any of the instructions or warnings, please visit www.tripplite.com/support.

• This mounting bracket was designed to be installed and utilized ONLY as speciﬁed in this guide. Improper installation of this product

may cause damage or serious injury.

• This product should only be installed by someone of good mechanical ability, with basic building experience and a full understanding

of this instruction manual.

• Make sure that the mounting surface can safely support the combined load of the equipment and all attached hardware and

components.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws ﬁrmly, but do not over-tighten. Over-tightening can damage the items, greatly reducing their holding power.

• This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 5 years from the date

of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, in its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES

OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES

OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND

CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you speciﬁc legal rights, and you may have other rights which vary from

jurisdiction to jurisdiction).

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are

subject to great variation, the manufacturer makes no representation or warranty as to the suitability or ﬁtness of these devices for any speciﬁc application.

PRODUCT REGISTRATION

Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice.

IMPORTANT: Ensure all parts according to the component checklist have been received prior to installation. If any parts are

missing or faulty, visit www.tripplite.com/support for service.

Component Checklist

M5x10 (x8) M5 Flat

Washer (x8)

LCD Mounting Plate

(x1)

M6x16 (x8)Rack Bracket (x2) M6 Cage

Nuts (x8)

M6 Cup

Washer (x8)

Installation

Attach LCD Mounting Plate to LCD Panel

M5x10

M5 Flat Washer

LCD Mounting Plate
