Installation Guide

SmartRack

Mounting Bracket for

2- and 4-Post Open Frame Racks

Adds keyhole slots and threaded holes for mounting vertical PDUs and cable management accessories

to any Tripp Lite 2-post, 4-post, standard or heavy-duty rack. Holds up to 3 vertical PDUs.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Package Includes

Mounting Brackets

(x2)

Adapter Plates

for Open Frame Racks

(x2)

M6 Screws

(x4)

Cage Nuts

(x4)

8-32 Flange Nuts

(x4)

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

20-01-403 93-3C26_RevA

For Use with 2-Post and

4-Post Open Frame Racks

For Use with Standard or

Heavy-Duty Rack Enclosures

Attach a mounting bracket to an adapter plate using two

8-32 ﬂange nuts.

Attach one mounting bracket directly into holes in the

rack frame using two M6 screws and two cage nuts.

Mount one bracket and adapter plate assembly into pre-

threaded holes near the top of the rack frame using two

M6 screws.

Repeat with the second bracket and adapter plate

assembly at a lower point of the rack frame in

accordance with the length of the PDUs to be mounted in

the rack.

Mount vertical PDUs (up to 3) or cable management

accessories using the keyhole slots in the top and bottom

brackets.

Repeat with the second bracket and adapter plate

assembly at a lower point of the rack frame in

accordance with the length of the PDUs to be mounted in

the rack.

Mount vertical PDUs (up to 3) or cable management

accessories using the keyhole slots in the top and bottom

brackets.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	SRPDU4PHDBRKT
Opprinnelsesland:	China
Pakkevekt:	590 g
Antall per pakke:	2 stykker
Produktfarge:	Sort
Pakkedybde:	85 mm
Pakkehøyde:	59.9 mm
Pakkebredde:	304.8 mm
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8302.50.0000
Modell/Type:	Monteringsbrakett
Kroppsmateriale:	Stål
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332252729
Masterkassens (ytterkassens) bruttovekt:	13020 g
Masterkassens (ytterkassens) lengde:	325.1 mm
Produkter per masterkasse (ytterkasse):	20 stykker
Masterkassens (ytterkassens) bredde:	449.8 mm
Masterkassens (ytterkassens) høyde:	260 mm
Pakkeinnhold:	2 Adapter plates, 4 M6 screws, 4 Cage nuts, 4 8-32 flange nuts
Form på montasjehull:	Rund
