Owner’s Manual

Cable Continuity Tester

with Power over Ethernet

(PoE) Detection

Model: T013-001-POE

Español 9 • Français 17 •  25

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

16-08-515-933624.indb 1 9/20/2016 9:44:09 AM

Package Contents

Product Features

• Main Tester Unit

• Remote Tester Unit

• 9V Battery

• Owner’s Manual

• All-in-One cable tester combines a Main

Tester unit with a Removable Remote Tester

unit

• Test cable connectivity to determine a

connection, no connection, short, or crossed

connection

• Capable of testing RJ11 and RJ45 cables

• Test live Ethernet cables to determine if

power and data are present

• Identify the Power Sourcing Equipment type

in a network (Endspan, Midspan or both)

• Identify the PoE standard used –

IEEE 802.3af (15.4W PoE) or IEEE 802.3at

(30W PoE+)

• Compact design speciﬁcally tailored for

system integrators and installers

16-08-515-933624.indb 2 9/20/2016 9:44:09 AM

Continuity Testing

Notes:

• Electriﬁed cabling cannot be used when testing

continuity.

• If LED lights appear weak or if the tester unit has

not been used for an extended period, replace

the 9V battery.

When testing an uninstalled patch cable,

the Main and Remote testers may remain

connected. When testing installed cable, the

Remote Tester will need to be removed from

the Main Tester. Connect one end of the cable

to the appropriate connector on the Main

Tester and the other end of the cable to the

appropriate connector on the Remote Tester.

If this is the ﬁrst time using the product, insert

a 9V battery into the Main Tester unit’s battery

compartment. After inserting the battery,

initiating testing is as simple as connecting

the desired cable and ﬂipping the unit’s On/Off

switch. Turning the switch to the On position

will cause the LEDs to blink fast during testing,

while turning the switch to S will cause LEDs

to blink slow. Otherwise, testing is the same

for both.

16-08-515-933624.indb 3 9/20/2016 9:44:09 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	kabler for datamaskiner og annet
Modell:	T013-001-POE
Produkttype:	PoE-tester
Innebygd skjerm:	Nei
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	230 g
Nettverksstandard:	IEEE 802.3af, IEEE 802.3at
Kabeltype:	Cat5e/Cat6/Cat6a
Testtype:	PoE tester, Short circuit testing
Produktfarge:	Sort
Pakkedybde:	147.3 mm
Pakkehøyde:	40.6 mm
Pakkebredde:	111.8 mm
Batterispenning:	9 V
Bærekraftsertifikater:	RoHS
Støttede kontakter:	RJ-11, RJ-45
Lett å bruke:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332199727
Masterkassens (ytterkassens) bruttovekt:	2270 g
Masterkassens (ytterkassens) lengde:	477.5 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	198.1 mm
Masterkassens (ytterkassens) høyde:	121.9 mm
