Owner’s Manual

Power over Ethernet

Tester

Model: T015-POE

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 20 • Français 39 • Русский 58

19-10-184-933B7C.indb 1 12/10/2019 2:01:01 PM

General Safety Instructions

• The emitter unit is powered by three AAA 1.5V dry-cell

batteries. The remote unit does not need supplied power.

• Use only batteries that meet the above speciﬁcations to avoid

damaging the tester.

• Do not place the tester in a location that is dusty, humid or

above 104°F (40°C).

•

Do not disassemble the tester. There are no user-serviceable parts.

• When the tester will not be used for an extended period,

remove the batteries to prevent battery leakage and damage

to the unit.

• Do not use the tester to detect live power lines (such as 220V

power supply lines); damage to the unit or personal injury

may occur.

• Do not perform operations on communications lines during

thunderstorms in order to prevent personal injury from

lightning strikes.

19-10-184-933B7C.indb 2 12/10/2019 2:01:01 PM

Typical Applications

Package Contents

• Test the information of standard/non-standard PoE devices,

such as voltage, polarity, midspan or endspan

• Identify the power-supplying equipment (PSE) type, 802.3af or

802.3at standard

• Test the real-time power consumed by Power Delivery (PD)

devices in PoE power supply systems

• Test the open, short and cross status in the network cable

• Test the power consumed by DC applications

• Test the loopback function of a switch

• Emitter Unit

• Remote Unit

• Cable Lead

• AAA Batteries (3x)

• Carrying Case

• Owner’s Manual

19-10-184-933B7C.indb 3 12/10/2019 2:01:01 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	kabler for datamaskiner og annet
Modell:	T015-POE
Produkttype:	PoE-tester
Innebygd skjerm:	Ja
Vekt:	150 g
Bredde:	25.2 mm
Dybde:	69.5 mm
Høyde:	28.1 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	320 g
Sertifisering:	CE, NOM
Nettverksstandard:	IEEE 802.3af, IEEE 802.3at
Batteriteknologi:	Alkalinsk
Batteritype:	AAA
Testtype:	Continuity testing, PoE tester, Transmission testing
Produktfarge:	Grå
Pakkedybde:	115 mm
Pakkehøyde:	50 mm
Pakkebredde:	199.9 mm
Antall støttede batterier:	3
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 45 °C
Bærekraftsertifikater:	REACH, RoHS
Av/på-bryter:	Ja
Støttede kontakter:	RJ-45
Relativ luftfuktighet under drift (H-H):	20 - 70
Batterier medfølger:	Ja
Strøm-LED:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332251500
Masterkassens (ytterkassens) bruttovekt:	3250 g
Masterkassens (ytterkassens) lengde:	250 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	280 mm
Masterkassens (ytterkassens) høyde:	220 mm
Oppbevaringsveske:	Ja
