Owner’s Manual

HDMI/Mini HDMI

Cable Tester

Model: T040-001-HDMI

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Este manual esta disponible en español en la página de Tripp Lite:

www.tripplite.com/support

Ce manuel est disponible en français sur le site Web de Tripp Lite :

www.tripplite.com/support

Русскоязычная версия настоящего руководства

представлена на веб-сайте компании Tripp Lite по адресу:

www.tripplite.com/support

10-413-933794-EN.indd 1 11/15/2017 9:41:19 A

Package Contents

Product Features

• Master Unit

• Remote Unit

• Carrying Case

• Owner’s Manual

• All-in-one unit combines a Main Tester with a removable Remote Identiﬁer

• Compatible with HDMI versions 1.0 through 2.1

• Fast and accurate veriﬁcation of HDMI cables with Type A-A, A-C or C-C

connectors

• Displays 19 pin-to-pin wire map and shield connection status to ensure

mapping continuity and proper conﬁguration

• Two adjustable test modes available: Continuity and Sweep

10-413-933794-EN.indd 2 11/15/2017 9:41:19 A

Operation

Note: Before testing, insert a 9V battery (not included) and ensure the cable being

tested is not yet connected to the tester.

Testing

Simply connect the desired cable to the unit, then switch the Sweep/OFF/

Continuity button to “Continuity” for sync testing, or “Sweep” for step-by-

step testing.

Note: During sync testing, all LEDs illuminate on the wire map at once. During step-by-

step testing, the LEDs will illuminate one at a time.

When testing uninstalled patch cable, you can leave the Main Tester and

Remote Identiﬁer connected.

When testing installed cable, you will need to remove the Remote

Identiﬁer from the Main Tester. Connect one end of the cable to the

appropriate connector on the Main Tester, and the other end of the cable to

the appropriate connector on the Remote Identiﬁer.

Note: Upon switching to the desired testing mode, the LEDs on the Main Tester and

Remote Identiﬁer will illuminate to indicate the results.

If testing HDMI A-to-A cables, use “A pin” side numbers found on both

the Main Tester and Remote Identiﬁer. For HDMI A-to-C and C-to-C cables,

use “C pin” side numbers found on both the Main Tester and Remote

Identiﬁer.

10-413-933794-EN.indd 3 11/15/2017 9:41:19 A
