Side 1/8

Owner’s Manual

USB Peripheral

Sharing Switch

Model #: U215-004-R

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

15-06-170-933487_EN.indd 1 6/23/2015 2:01:27 PM

Table of Contents

Quick Installation 3

Installation Figure 3

Installing the Software 3

Status Indication on Taskbar 3

Features 4

Troubleshooting 5

Windows and Mac Sleep Mode 5

Windows 5

Mac OS 6

Hotkey Control Problems in Mac OS X 7

Warranty and Product Registration 8

15-06-170-933487_EN.indd 2 6/23/2015 2:01:27 PM

Quick Installation

Installation Figure

Installing the Software

Installing the USB Sharing Application:

• Insert the application CD in your computer’s CD-ROM drive to start the installation process. If

your computer does not have a CD-ROM drive, you can download the software from Tripp Lite’s

website at www.tripplite.com/support.

• If the installation does not automatically start, navigate to your CD-ROM drive in your Computer

window (for Windows systems) or in Finder (for Mac OS X), and double-click the corresponding

driver ﬁle.

• The Install page is displayed. The installation process will only take a few seconds.

• When the End of Installation dialog box is displayed, click “Finished”.

Note: We highly recommend that you reboot your PC after installation.

Status Indication on Taskbar

Color of Status Indicator:

Red Another computer is using the device; you may not switch between PCs at this

moment (busy status).

Green Device is now connected.

Yellow Device is currently connected to another computer. Press Ctrl + F11 to switch, or

right-click with the mouse and select “switch” (for Mac OS X, use Alt + F11).

Note: The status indicator on the Taskbar will be GREEN for ALL computers if the switch is improperly installed.

Storage devices such as external hard drives and printers will continue to send signals back and forth to your

computer whenever they are connected. When this occurs, the indicator icon will appear red and blinking. If

you would like to control the USB Peripheral Sharing Switch without busy statuses, simply press Ctrl + F11 (for

Mac OS X, use Alt + F11) and the conﬁrmation message will open. Click “Yes” to conﬁrm the switch.

Flash Drive

15-06-170-933487_EN.indd 3 6/23/2015 2:01:30 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U215-004-R
LED-indikatorer:	Ja
Strømkildetype:	USB
Opprinnelsesland:	China
Pakkevekt:	160 g
Antall USB 2.0-porter:	5
Sertifisering:	FCC, CE
Vertsgrensesnitt:	USB 2.0
Antall porter:	4
Produktfarge:	Sølv
Pakkedybde:	40.9 mm
Pakkehøyde:	134.1 mm
Pakkebredde:	122.9 mm
Kabler inkludert:	USB
Harmonisert system (HS)-kode:	8517.62.0090
USB-strøm:	Ja
Støttede Mac operativsystemer:	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Grensesnitt (hub):	USB 2.0
Overføringshastighet (Mbps):	480 Mbit/s
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332190366
Masterkassens (ytterkassens) bruttovekt:	200 g
Masterkassens (ytterkassens) lengde:	140 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	240 mm
Masterkassens (ytterkassens) høyde:	300 mm
Minstekrav til systemet:	USB, CD-ROM
