Side 1/25

Quick Start Guide

USB 3.1 Gen 1 to

DVI Alternate Mode

Adapter

Model: U444-06N-DVI-AM (White),

U444-06N-DVIBAM (Black)

Español 8 • Français 14 • Русский 20

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

17-10-087-93376C.indb 1 11/20/2017 10:24:47 AM

Product Features

• Connects your existing DVI TV, monitor or projector

to the USB-C or Thunderbolt 3 port on your

tablet, laptop, notebook, MacBook, Chromebook,

smartphone or PC

• Supports USB DisplayPort Alternate Mode for

transmitting video

• Supports USB 3.1 Gen 1 data transfer rates up to

5 Gbps

• Supports HD video resolutions up to 1920 x 1080

(1080p) @ 60 Hz

• Supports 36-bit Deep Color (12 bits per channel)

• Supports DVI transfer rates up to 6.75 Gbps

(2.25 Gbps per channel)

• Plug-and-play adapter—no software, drivers or

external power required

USB Type-C™ and USB-C™ are trademarks of USB

Implementers Forum.

17-10-087-93376C.indb 2 11/20/2017 10:24:47 AM

System Requirements

Installation

Package Contents

• USB Type-C (USB-C) device that supports USB

DisplayPort Alternate Mode

• DVI-enabled monitor

1. Connect the adapter’s USB Type-C connector

to the USB Type-C port on your tablet, laptop,

notebook, MacBook, Chromebook, smartphone

or PC.

2. Connect the adapter’s DVI port to a monitor using

a DVI cable (such as Tripp Lite’s P561-Series

cables).

3. The video image will appear on the add-on

monitor. Customize how video is displayed on

the add-on monitor using your device’s display

settings.

• U444-06N-DVI-AM (White) or

U444-06N-DVIBAM (Black)

• Quick Start Guide

17-10-087-93376C.indb 3 11/20/2017 10:24:47 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U444-06N-DVIBAM
Vekt:	22.68 g
Bredde:	45.72 mm
Dybde:	43.18 mm
Høyde:	14.48 mm
Strømkilde:	USB
Maksimal oppløsning:	1920 x 1080 piksler
Opprinnelsesland:	China
Pakkevekt:	90 g
Sertifisering:	CE, FCC, REACH
Kabelfarge:	Svart/gult
Tilkobling 1:	USB Type-C
Tilkobling 2:	DVI-D
Kabellengde:	0.15 m
Produktfarge:	Sort
Pakkedybde:	121.9 mm
Pakkehøyde:	20.3 mm
Pakkebredde:	96.5 mm
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Støttede videofunksjoner:	1080p
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Bærekraftsertifikater:	RoHS
Relativ luftfuktighet under drift (H-H):	10 - 85
Plugg inn og spill:	Ja
Kontaktplettering:	Nickel
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332210705
Masterkassens (ytterkassens) bruttovekt:	640 g
Masterkassens (ytterkassens) lengde:	246.4 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	116.8 mm
Masterkassens (ytterkassens) høyde:	127 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
Tilkobling 1 formfaktor:	Rett
Kontakttype:	USB C
