Side 1/4

Quick Start Guide

USB 3.0 Gigabit

Ethernet Adapter

Model: U336-000-GB-AL

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

15-07-239-9334C1.indd 1 7/28/2015 12:32:07 PM

Product Features

System Requirements

Package Contents

• Plug-and-play – no drivers required

• Compact aluminum case is perfect for travel; ﬁts easily into the pocket of

a laptop bag or briefcase

• USB 3.0 ensures true 10/100/1000 Mbps network speeds

• Compliant with IEEE 802.3, 802.3u and 802.3ab standards

• IEEE 802.3az (Energy Efﬁcient Ethernet) compliant

• Supports Wake-on-LAN

• Supports full duplex with IEEE 802.3x ﬂow control and half duplex with

back-pressure ﬂow control

• Supports IPv4 and IPv6 pack Checksum Ofﬂoad Engine (COE) to reduce

CPU loading

• Suspend mode and remote wake-up supported via link-change, Magic

Packet, Microsoft Wakeup Frame and external wakeup pin

• Available USB port (USB 3.0 port required to achieve USB 3.0 speeds)

• Compatible with Windows, Mac and Linux

• U336-000-GB-AL

• Quick Start Guide

15-07-239-9334C1.indd 2 7/28/2015 12:32:07 PM

Installation

Warranty and Product Registration

1. Connect the adapter’s USB connector to the USB port on your laptop,

ultrabook or computer.

2. Connect the adapter’s RJ45 port to a network using a UTP cable, such

as Tripp Lite’s N201-Series Cat6 cables.

3. The adapter includes three status LED lights. The white LED will

illuminate when the adapter is connected to your computer’s USB port.

The green and yellow LEDs illuminate when a network connection has

been made.

• White LED – A solid light indicates the adapter is powered

• Green LED – A solid light indicates a successful connection to the

network

• Yellow LED – A ﬂickering light indicates data transfer

1- YEAR LIMITED WARRANTY

Seller warrants this product, if used in accordance with all applicable instructions, to be free from

original defects in material and workmanship for a period of 1 year from the date of initial purchase.

If the product should prove defective in material or workmanship within that period, Seller will repair

or replace the product, in its sole discretion. Service under this Warranty can only be obtained by your

delivering or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W.

35th Street, Chicago, IL 60609 USA. Seller will pay return shipping charges. Visit www.tripplite.com/

support before sending any equipment back for repair.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT,

MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE

WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE

LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS,

ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY

EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not

allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion

or limitation of incidental or consequential damages, so the above limitations or exclusions may not

apply to you. This Warranty gives you speciﬁc legal rights, and you may have other rights which vary

from jurisdiction to jurisdiction).

WARNING: The individual user should take care to determine prior to use whether this device is

suitable, adequate or safe for the use intended. Since individual applications are subject to great

variation, the manufacturer makes no representation or warranty as to the suitability or ﬁtness of

these devices for any speciﬁc application.

15-07-239-9334C1.indd 3 7/28/2015 12:32:07 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U336-000-GB-AL
Vekt:	40 g
Opprinnelsesland:	China
Pakkevekt:	80 g
Antall per pakke:	1 stykker
Tilkobling 1:	USB 3.0 A
Tilkobling 2:	USB 3.0 A
Produktfarge:	Sølv
Pakkedybde:	119.4 mm
Pakkehøyde:	31 mm
Pakkebredde:	101.6 mm
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84733080
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332190526
Masterkassens (ytterkassens) bruttovekt:	820 g
Masterkassens (ytterkassens) lengde:	327.7 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	114.3 mm
Masterkassens (ytterkassens) høyde:	139.7 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hankjønn
