Side 1/52

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Safety Instructions 2

Features 3

System Requirements 3

Package Contents 3

Powering the Hub 4

Mounting Kit Installation 5

Specications 7

Warranty & Product Registration 8

Regulatory Compliance 9

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

tripplite.com/warranty

Industrial USB 2.0 Hub

Models:

U223-004-IND(4-Port),U223-007-IND(7-Port)

Español11•Français21•Русский31•Deutsch41

23-05-201-934819.indb 123-05-201-934819.indb 1 6/15/2023 10:49:19 AM6/15/2023 10:49:19 AM

Before attempting to connect, operate or adjust this product, please

read the entire Owner’s Manual rst.

Safety Instructions

• Always read the safety instructions carefully

• Keep this Owner’s Manual for future reference

• If any of the following situations arise, schedule an appointment to

have your equipment inspected by a service technician:

The equipment has been exposed to moisture

The equipment has been dropped and damaged

The equipment shows obvious signs of breakage

The equipment is not functioning properly or is not functioning

according to the Owner’s Manual instructions

23-05-201-934819.indb 223-05-201-934819.indb 2 6/15/2023 10:49:19 AM6/15/2023 10:49:19 AM

Features

• Increases the number of High Speed USB ports via a single computer

port (4 ports for U223-004-IND model / 7 ports for U223-007-IND

model)

• USB 2.0 compliant with data transfer rates up to 480Mbps

• Backwards compatible with USB 1.1

• Rugged all-metal enclosure designed for use in industrial applications

• Wall-mount and DIN rail hardware included for secure installation

• Three power connection options (source USB port, external power

supply (not included) or 3-wire terminal block)

• Over-current detection and protection

• ESD protection to +/- 15 kV

• Automatic link and speed detection

• Plug-and-play; no software or drivers required

System Requirements

• Compatible with all USB-enabled operating systems

Package Contents

• U223-004-IND or U223-007-IND Industrial USB 2.0 Hub

• USB 2.0 cable

• 3-pin power terminal block

• DIN mounting hardware

• Wall-mount hardware

• Owner’s Manual

23-05-201-934819.indb 323-05-201-934819.indb 3 6/15/2023 10:49:19 AM6/15/2023 10:49:19 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	U223-004-IND
Vekt:	320 g
Bredde:	139.7 mm
Dybde:	63.5 mm
Høyde:	25.4 mm
Opprinnelsesland:	China
Pakkevekt:	640 g
Antall USB 2.0-porter:	4
Vertsgrensesnitt:	USB 2.0
Antall porter:	4
Produktfarge:	Sort
Pakkedybde:	231.1 mm
Pakkehøyde:	76.2 mm
Pakkebredde:	160 mm
Driftstemperatur (T-T):	0 - 60 °C
Harmonisert system (HS)-kode:	84719000
Kroppsmateriale:	Metall
DC-inngangskontakt:	Ja
Relativ luftfuktighet under drift (H-H):	5 - 95
Grensesnitt (hub):	USB 2.0
Overføringshastighet (Mbps):	480 Mbit/s
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332174281
Masterkassens (ytterkassens) bruttovekt:	12020 g
Masterkassens (ytterkassens) lengde:	480.1 mm
Produkter per masterkasse (ytterkasse):	20 stykker
Masterkassens (ytterkassens) bredde:	342.9 mm
Masterkassens (ytterkassens) høyde:	386.1 mm
