Side 1/12

Owner’s Manual

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

USB to VGA/DVI Adapter

Model #: U244-001-R

USB to VGA Adapter

Model #: U244-001-VGA-R

USB to HDMI Adapter

Model #: U244-001-HDMI-R

Table of Contents

1. Introduction 2

1.1 Features 2

1.2 Package Contents 2

1.3 System Requirements 2

2. Installation 3

3. Using the Adapter 4

3.1 Display Properties 4

3.2 Extending Video to the Add-On Display 6

3.3 Mirroring Video on the Add-On Display 8

3.4 Making the Add-On Display the Primary Display 8

4. Troubleshooting 9

5. Speciﬁcations 11

6. Warranty And Warranty Registration 12

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

201108084-93-3099.indd 1 8/12/2011 4:40:37 PM

1. Introduction

1.1 Features

• Addsanadditionalmonitor,LCDorprojectorthroughasingleUSB2.0port

• Simultaneouslyconnectupto6displayadapterstoaWindowscomputerorupto4

on a Mac

• Hot-pluggable;addorremovemonitorwithouttheneedforasystemreboot

• Automaticallyresumesfromhibernationandsuspendmodes

• Supportsvideoresolutionsupto1920x1080(60Hz),1080p(60Hz)

• Setadditionalmonitorstoextendtheprimarydisplay,duplicatetheprimarydisplay,

or set an additional monitor as the primary display

• U244-001-RcomeswithaDVItoVGAadapter,allowingyoutoconnecteithera

DVIorVGAdisplay

1.2 Package Contents

Before installation, please check the items in the package. The package should

contain the following items:

•(1)U244-001-Ror(1)U244-001-VGA-Ror(1)U244-001-HDMI-R

• (1)DriverCD

•(1)USBCable

•(1)Owner'sManual

•(1)DVItoVGAAdapter(U244-001-Ronly)

1.3 System Requirements

Windows

• Windows2000orlater

• USB2.0port

• VGA,DVIorHDMImonitor

Mac

• AnIntel-basedMacrunningOSX10.4orlater.PowerPC-basedMacsarenot

supported.

• USB2.0port

• VGA,DVIorHDMImonitor

201108084-93-3099.indd 2 8/12/2011 4:40:38 PM

1. Introduction

Computer requirements when using 1 – 2 display adapters:

 • 1.2GHzSingleCoreCPU

 • 512MBmemory

Computer requirements when using 3 display adapters:

 • 1.8GHzSingleCoreCPU

 • 1GBmemory

Computer requirements when using 4 – 6 display adapters:

 • 1.6GHzCoreDuoCPU

 • 1GBmemory

Note: Only 1 added monitor can support DVD playback. In order to support

DVD playback, your computer must meet the following requirements:

 • 2.0GHzCoreDuoCPU

 • 1GBmemory

 • Adapterscreenresolutionmustbesetto800x600with16-bitcolor

2. Installation

Note: Install the driver on your computer before connecting the display

adapter(s).

1.InsertthedriverCDintoyourcomputer’sCD-ROMdrive.Thesetupprogramshould

runautomatically.Ifthesetupprogramfailstostartonitsown,opentheCDand

double-clickontheappropriatedriverle,dependingonyourOS.

Note:

• ForWindows2000users,ifpromptedforasystempatch,youmust

download and install the required patch before the driver can be

installed.

• ForWindowsVistaand7users,ifyouencounteraUserAccountControl

popup, choose to allow the installation to proceed. This may require an

administrator’s password. If you encounter a driver signature dialog box,

choose to continue the installation anyways.

• Ifamessagestating“DisplayLinksoftwareforUSBdisplayadapteris

already up to date,” then the necessary software for this unit is already

installed, and you can proceed to step 5.

201108084-93-3099.indd 3 8/12/2011 4:40:38 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	netverkskort/adapter
Modell:	U244-001-R
Vekt:	60 g
Strømkilde:	USB
Opprinnelsesland:	China
Pakkevekt:	230 g
Antall per pakke:	1 stykker
Tilkobling 1:	Micro USB Type-A
Tilkobling 2:	DVI-I
Kabellengde:	0.9 m
Produktfarge:	Antrasitt
Pakkedybde:	57.2 mm
Pakkehøyde:	215.9 mm
Pakkebredde:	152.4 mm
Bærekraftsertifikater:	RoHS
Masterkassens (ytterkassens) GTIN (EAN/UPC):	20037332143383
Masterkassens (ytterkassens) bruttovekt:	5490 g
Masterkassens (ytterkassens) lengde:	246.4 mm
Produkter per masterkasse (ytterkasse):	20 stykker
Masterkassens (ytterkassens) bredde:	350.5 mm
Masterkassens (ytterkassens) høyde:	373.4 mm
Connector 1 kjønn:	Hunkjønn
Connector 2 kjønn:	Hunkjønn
Omformertype:	Aktiv
