Side 1/16

Quick Start Guide

USB 2.0 10/100 Mbps Ethernet Adapter

Model: U236-000-R (Black)

USB 2.0 Gigabit Ethernet Adapter

Model: U236-000-GBW (White)

USB 3.0 Gigabit Ethernet Adapter

Models: U336-000-GBW (White) and U336-000-R (Black)

Espanol 5 • Français 9 • Русский 13

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

17-11-343-9337C0.indb 1 12/7/2017 10:45:52 AM

Product Features

System Requirements

Package Contents

• U236-000-R ensures true 10/100 Mbps network speeds

• U236-000-GBW supports Gigabit networks at speeds up to 480 Mbps

• U336-000-R and U336-000-GBW ensure true 10/100/1000 Mbps

network speeds

• Compliant with IEEE 802.3, 802.3u, and 802.3ab standards

• IEEE 802.3az (Energy Efficient Ethernet) compliant

• Supports full-duplex with IEEE 802.3x flow control and half-duplex with

back-pressure flow control

• Supports IPv4 and IPv6 pack Checksum Offload Engine (COE) to reduce

CPU loading

• Suspend mode and remote wakeup supported via link-change, Magic

Packet, Microsoft

Wakeup Frame and external wakeup pin

• Supports Wake-on-LAN

• An available USB port

• Compatible with Windows

, Mac

and Linux

• USB Ethernet Adapter

• Quick Start Guide

17-11-343-9337C0.indb 2 12/7/2017 10:45:52 AM

Installation

Warranty and Product Registration

1. Plug the USB connector on the adapter into an available USB port on

your computer. Upon connecting the adapter to your computer, the

device will begin installing.

2. Wait for the installation process to reach completion. You may need to

restart your computer.

3. Connect the Ethernet port on the adapter to your LAN port using a

Cat5e/6 cable.

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of

three (3) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited

to repairing or replacing (at its sole option) any such defective products. To obtain service under

this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or

an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized

TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief

description of the problem encountered and proof of date and place of purchase. This warranty does

not apply to equipment, which has been damaged by accident, negligence or misapplication or has

been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED,

INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid

limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT,

EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any

costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software,

loss of data, costs of substitutes, claims by third parties, or otherwise.

17-11-343-9337C0.indb 3 12/7/2017 10:45:52 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	netverkskort/adapter
Modell:	U336-000-GBW
Vekt:	30 g
Bredde:	22.7 mm
Dybde:	15.2 mm
Høyde:	66 mm
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Opprinnelsesland:	Vietnam
Pakkevekt:	40 g
Kablingsteknologi:	10/100/1000BaseT(X)
Nettverksstandard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Vertsgrensesnitt:	USB
Maksimal dataoverføringshastighet:	1000 Mbit/s
Minimum RAM:	64 MB
Produktfarge:	Hvit
Antall USB-porter:	1
Pakkedybde:	100.1 mm
Pakkehøyde:	20.1 mm
Pakkebredde:	119.9 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85176990
Minimum prosessor:	Pentium 233MHz
USB-strøm:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Støttede Windows operativsystemer:	Ja
Ethernet-kobberkabelteknologi:	1000BASE-T, 100BASE-TX, 10BASE-T
Ethernet/bredbåndsforbindelse:	Ja
Drivere medfølger:	Ja
Videoopptaksgrensesnitt:	Ethernet
Intern:	Nei
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Full tosidig:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332183283
Masterkassens (ytterkassens) bruttovekt:	520 g
Masterkassens (ytterkassens) lengde:	119.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	255 mm
Masterkassens (ytterkassens) høyde:	115.1 mm
