Owner’s Manual

USB 3.0 to SATA / IDE

Adapter with

Built-in Cable

Model: U338-06N

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

WARRANTY REGISTRATION

to win an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Español 9 • Français 17

Package Contents

Product Features

• U338-06N USB 3.0 to SATA / IDE Adapter

• 7-Pin SATA Data Cable

• 15-Pin SATA Power Cable

• 4-Pin Molex Power Cable

• Power Supply Adapter

• External Power Supply (Input: 100-240V,

50/60 Hz, 1.5A; Output: 12V 2A)

• Owner’s Manual

• Supports USB 3.0 SuperSpeed speciﬁcation;

backward compatible with USB 2.0 and 1.1

• Allows easy hard drive access without having

to connect the drive internally

• Features SATA, 40-Pin and 44-Pin

connectors for use with 2.5", 3.5" or 5.25"

drives

• Compatible with Windows

, Mac

, and

Linux

operating systems

• Plug-and-Play—no software or drivers

required

System Requirements

Installation

• Computer with an available USB port; a

USB 3.0 port is required to achieve USB 3.0

data transfer rates

• 2.5" / 3.5" / 5.25" SATA or IDE drive

Notes:

• Hard drives are sensitive to static electricity and

must be handled properly to prevent data loss.

Always handle your hard drive with caution. Wear

an anti-static strap (such as the Tripp Lite

P999-000) when transporting it, or touch a

grounded metal surface to discharge yourself of

static electricity before picking up the drive.

• If your drive has not been formatted, you must

format it using your computer’s Disk Management

utility before you can copy and access ﬁles.

• For all IDE devices, set the Jumper setting on the

drive to Master Single drive mode. For Jumper

settings, refer to your hard drive manufacturer’s

documentation.

• Before unplugging the adapter, make sure to

properly eject the drive from your computer to

avoid any potential data loss.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U338-06N
Vekt:	40 g
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	270 g
Antall per pakke:	1 stykker
Inngangsspenning:	100-240 V
Utgangsstrøm:	12 V
Tilkobling 1:	USB 3.0 A
Tilkobling 2:	7 PIN SATA, 40 POS. SOCKET
Dataoverføringshastighet:	6 Gbit/s
Kabellengde:	0.02 m
Produktfarge:	Sort
Pakkedybde:	170.2 mm
Pakkehøyde:	48.3 mm
Pakkebredde:	132.1 mm
Kabler inkludert:	SATA
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84719000
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332199741
Masterkassens (ytterkassens) bruttovekt:	2990 g
Masterkassens (ytterkassens) lengde:	276.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	266.7 mm
Masterkassens (ytterkassens) høyde:	195.6 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
