1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Owner’s Manual

USB 3.0 to 4K DisplayPort Adapter

Model #: U344-001-DP-4K

USB 3.0 to 4K HDMI Adapter

Model #: U344-001-HD-4K

Table of Contents

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1. Introduction 2

1.1 Features 2

1.2 Package Contents 2

1.3 System Requirements 3

2. Installation 4

3. Using the Adapter 5

3.1 Display Properties 5

3.2 Extending Video to the 7

Add-On Display

3.3 Mirroring Video on the 8

Add-On Display

3.4 Making the Add-On 8

Display the Primary Display

4. Troubleshooting 9

5. Speciﬁcations 11

6. Warranty And Product 12

Registration

15-11-191-933220.indd 1 12/9/2015 3:40:27 PM

1. Introduction

1.1 Features

• Adds an additional monitor, LCD or projector through a single USB port

• Adds 4K Ultra High Deﬁnition (UHD) support via a USB 3.0 port, even if a

computer’s graphics card does not support it

• USB 3.0 is 10 times faster than USB 2.0, with transfer rates up to 5 Gbps

• Backward compatible with USB 2.0

• Simultaneously connect up to 6 display adapters

• Automatically resumes from hibernation and suspend modes

• Supports 4K x 2K Ultra High Deﬁnition (UHD) video resolutions up to

3840 x 2160 @ 30Hz

• Set additional monitors to extend the primary display, duplicate the primary

display, or set an additional monitor as the primary display

1.2 Package Contents

Before installation, please check the items in the package. The package should

contain the following items:

• U344-001-DP-4K or U344-001-HD-4K

• Driver CD

• Owner's Manual

Optional Accessories:

• P568-Series High-Speed HDMI Cables

• P580-Series DIsplayPort Cables

15-11-191-933220.indd 2 12/9/2015 3:40:28 PM

1. Introduction

1.3 System Requirements

• Windows® Vista (32- and 64-bit)*, 7 (32- and 64-bit), 8 (32- and 64-bit) and

10 (32- and 64-bit)

*4K displays not supported on Windows Vista

• Compatible with Mac OS

X 10.8.5 and later (32- and 64-bit)

Notes:

• Mac OS X 10.8.5 and earlier does not support audio over USB 3.0

• Mac OS X 10.7.X and earlier does not support USB 3.0

• USB 2.0 or 3.0 port; USB 3.0 port required for USB 3.0 speeds and 4K video

resolution

• DisplayPort or HDMI monitor

Minimum computer requirements:

• Processor: 1.2 GHz or faster with support for SSE2

• RAM: 2 GB for 1 DisplayLink display; 4 GB or more is recommended for 2 or

more DisplayLink displays

• Graphics card (for PCs running Windows OS): Microsoft DirectX 10 or later

graphics device with WDDM driver

• USB: At least one USB 2.0 or USB 3.0 port

• 30 MB of free disk space

• Computer screen for use with the DisplayLink device (if one is not integrated)

• Network access for software downloads or access to a CD-ROM drive

Minimum computer requirements when supporting 4K playback:

• Processor: Intel Core i5 2 GHz or faster

• RAM: 4 GB for one 4K display; 8 GB or more is recommended for two 4K displays

• Graphics card: Intel HD 4000 or later

15-11-191-933220.indd 3 12/9/2015 3:40:28 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	kabler for datamaskiner og annet
Modell:	U344-001-DP-4K
Vekt:	317.5 g
Bredde:	25.4 mm
Dybde:	81.28 mm
Høyde:	10.16 mm
Strømkilde:	USB
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	China
Pakkevekt:	170 g
Antall per pakke:	1 stykker
Tilkobling 2:	DisplayPort
Dataoverføringshastighet:	5 Gbit/s
Produktfarge:	Sort
Pakkedybde:	39.9 mm
Pakkehøyde:	137.9 mm
Pakkebredde:	165.1 mm
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84733080
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332192131
Masterkassens (ytterkassens) bruttovekt:	1870 g
Masterkassens (ytterkassens) lengde:	175 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	214.9 mm
Masterkassens (ytterkassens) høyde:	297.9 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hankjønn
