Side 1/20

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

Owner’s Manual

USB 3.0 to DVI Adapter

Model #: U344-001-R

USB 3.0 to HDMI Adapter

Model #: U344-001-HDMI-R

All trademarks are the property of their respective owners.

PROTECT YOUR INVESTMENT!

ultimate peace of mind. You could also win an

ISOBAR6ULTRA surge protector—a $50 value!

www.tripplite.com/warranty

1. Introduction 3

1.1 Features 3

1.2 Package Contents 3

1.3 System Requirements 4

2. Installation 5

3. Using the Adapter 7

3.1 Display Properties 7

3.2 Extending Video to the Add-On Display 9

3.3 Mirroring Video on the Add-On Display 10

3.4 Making the Add-On Display the 11

Primary Display

4. Troubleshooting 12

5. Speciﬁcations 15

6. Warranty and Product Registration 16

Table of Contents

1. Introduction

1.1 Features

• Adds an additional monitor, LCD or projector through a single

USB 3.0 port

• USB 3.0 is 10 times faster than USB 2.0, with transfer rates

up to 5 Gbps

• Backward compatible with USB 2.0

• Simultaneously connect up to 6 display adapters on a

Windows

• Automatically resumes from hibernation and suspend modes

• Supports video resolutions up to 2048 x 1152 @ 60Hz

• Video streaming is supported up to 1080p

• Set additional monitors to extend the primary display,

duplicate the primary display, or set an additional monitor as

the primary display

• U344-001-R comes with a DVI to VGA adapter, allowing you

to connect either a DVI or VGA display

1.2 Package Contents

Before installation, please check the items in the

package. The package should contain the following items:

• (1) U344-001-R or (1) U344-001-HDMI-R

• (1) Driver CD

• (1) USB 3.0 Cable (U344-001-R only; cable is attached to

U344-001-HDMI-R)

• (1) Owner's Manual

• (1) DVI to VGA Adapter (U344-001-R only)

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	U344-001-R
Vekt:	50 g
Bredde:	47.6 mm
Dybde:	95.2 mm
Høyde:	20.7 mm
Maksimal oppløsning:	2048 x 1152 piksler
Opprinnelsesland:	China
Pakkevekt:	170 g
Kompatible operativsystemer:	Windows XP, Vista, 7, 8
Tilkobling 1:	USB 3.0
Tilkobling 2:	DVI-I
Produktfarge:	Sort
Pakkedybde:	45.7 mm
Pakkehøyde:	111.8 mm
Pakkebredde:	109.2 mm
Kabler inkludert:	USB
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332174212
Masterkassens (ytterkassens) bruttovekt:	9530 g
Masterkassens (ytterkassens) lengde:	248.9 mm
Produkter per masterkasse (ytterkasse):	50 stykker
Masterkassens (ytterkassens) bredde:	248.9 mm
Masterkassens (ytterkassens) høyde:	579.1 mm
Connector 1 kjønn:	Hunkjønn
Connector 2 kjønn:	Hunkjønn
