Side 1/16

Owner’s Manual

USB 3.0 Peripheral

Sharing Switch

Models: 2-Port (U359-002), 4-Port (U359-004)

Español 5 • Français 9 • Русский 13

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

18-10-320-933828.indb 1 11/5/2018 1:43:06 PM

Product Features:

Package Includes:

System Requirements:

• Up to 2 (U359-002) or 4 (U359-004) computers can share a USB 3.0

printer, ﬂash drive or other device

• Backward compatible with USB 2.0 and 1.1

• Features instant switching, delivering one-touch port control via manual

push button

• Supports SuperSpeed data transfer speeds up to 5 Gbps

• Supports all major operating systems that have a USB port

• Hot-pluggable

• Bus-powered; no power supply required

• 2- or 4-Port USB 3.0 Peripheral Sharing Switch

• Owner’s Manual

• Computers with available USB ports

• USB Device

18-10-320-933828.indb 2 11/5/2018 1:43:06 PM

Quick Installation:

Warranty and Product Registration

Notes:

• When using the USB Peripheral Sharing Switch to share a USB storage device, you

must eject the device before switching ports in order to avoid any data loss.

• Although these switches do not require any software or drivers, the peripheral device

that you are sharing between may. Please be sure that you have installed the latest

drivers for your peripheral onto both systems before connecting to avoid detection or

functionality issues.

• Be sure your computer is powered on prior to installation.

• Maximum distance from host device to peripheral is 5 m (16 ft.).

• A USB hub can connect to a USB port on the switch, allowing you to add multiple

USB peripherals to the installation. To ensure proper function, it is recommended to

use a hub with an external power supply.

1. Connect your USB peripheral device to the USB-A port on the switch.

2. Connect the ﬁrst PC to the switch using a user-supplied USB 3.0 cable.

The computer will detect the switch, and it will be recognized in the

Device Manager or System Preferences section.

3. Repeat Step 2 for the remaining ports that need to be connected with

user-supplied USB 3.0 cables.

4. Once all ports needed are connected, the LEDs on top of the switch will

indicate which computer is selected. To switch from one port to another,

use the push buttons.

3-Year Limited Warranty

Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of

three (3) years from the date of initial purchase. Tripp Lite’s obligation under this warranty is limited

to repairing or replacing (at its sole option) any such defective products. To obtain service under this

warranty, you must obtain a Returned Material Authorization (RMA) number from Tripp Lite or an

authorized Tripp Lite service center. Products must be returned to Tripp Lite or an authorized Tripp Lite

service center with transportation charges prepaid and must be accompanied by a brief description

of the problem encountered and proof of date and place of purchase. This warranty does not apply to

equipment, which has been damaged by accident, negligence or misapplication or has been altered

or modiﬁed in any way.

18-10-320-933828.indb 3 11/5/2018 1:43:06 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U359-004
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	210 g
Sertifisering:	CE, FCC, RoHS, REACH
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Antall porter:	4
Produktfarge:	Sort
Pakkedybde:	95 mm
Pakkehøyde:	37.1 mm
Pakkebredde:	113 mm
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 55 °C
Lagringsrelativ fuktighet:	5 - 95
Harmonisert system (HS)-kode:	8471.80.1000
Kroppsmateriale:	Metall
USB-strøm:	Ja
Relativ luftfuktighet under drift (H-H):	5 - 90
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	1
Grensesnitt (hub):	USB Type-B
Overføringshastighet (Mbps):	5000 Mbit/s
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332224788
Masterkassens (ytterkassens) bruttovekt:	2200 g
Masterkassens (ytterkassens) lengde:	214.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	235 mm
Masterkassens (ytterkassens) høyde:	110 mm
