Side 1/12

Owner’s Manual

3-Port USB 3.0 SuperSpeed

Hub with Keyboard/Mouse

Sharing and File Transfer

Model: U360-003-KM

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

15-11-229-9334BC.indd 1 12/9/2015 3:48:56 PM

Product Features

System Requirements

• Compact design easily ﬁts into a laptop bag—perfect for travel

• Supports USB 3.0 SuperSpeed data transfer rates up to 5 Gbps;

backwards compatible with USB 2.0 and 1.1

• Bus-powered through USB connection

• Additional USB port connects to another computer or On-the-Go

(OTG) compliant Android™ device (USB Micro-OTG adapter included)

to share a keyboard and mouse, and transfer ﬁles

• Built-in software allows for keyboard and mouse sharing between

computers, with the cursor able to travel from one screen to the next

• Includes clipboard sharing for copy-and-pasting between computers

• Built-in GO!Bridge ﬁle transfer software transfers ﬁles on Windows and

Mac computers, plus OTG compatible Android devices

• Supports 11 languages (English, Spanish, French, German, Italian,

Russian, Simpliﬁed Chinese, Traditional Chinese, Korean, Japanese

and Portuguese) with automatic switching capabilitly to match your

operating system’s language

• Compatible with all major operating systems with a USB port (USB

3.0 port is required to achieve USB 3.0 speeds)

• Windows

2000 SP3, XP, Vista, 7, 8 (Excluding RT), 8.1, and 10

• Mac OS

X 10.6 and later

• OTG compliant device with Google Android 2.2, 3.0, 3.1 and later

Android devices must install the Windroid Linker App—see GO!Bridge Note:

section of this manual for details

• Intel Pentium II Processor / PowerPC G4 processor or higher

• 256MB RAM or higher

• At least 50MB hard disk space

15-11-229-9334BC.indd 2 12/9/2015 3:48:56 PM

Package Includes

Optional Accessories

Setup

• U360-003-KM

• USB 2.0 Type-A (Male) to Type-A (Male) Cable for KM Share, 4 ft.

• USB 2.0 Micro-B (Male) to Type-A (Female) OTG Adapter

• Owner’s Manual

• M100-Series Lightning Cables

• M110-Series Apple 30-Pin Cables

• U322-Series USB 3.0 Type-A to Type-B Device Cables

• U326-Series USB 3.0 Type-A to Micro-B Device Cables

1. Connect the built-in USB 3.0 cable to an available USB port on your

computer or laptop.

2. Connect USB devices to the available hub ports located on the top of

the unit.

The hub is powered via the connected computer port (USB 3.0 Note:

provides up to 900mA). If you are connecting devices that require more

power than is being supplied by the connected computer port, they will need

to be powered by an external power supply.

3. To use the KM sharing and/or ﬁle transfer features, connect the

included USB cable between the SHARE port on the front of the

hub to an available USB port on a second computer, laptop or OTG

compatible Android device.

A USB Micro-B OTG Adapter is provided for connecting to Android Note:

devices).

15-11-229-9334BC.indd 3 12/9/2015 3:48:56 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U360-003-KM
Strømkildetype:	USB
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Antall porter:	4
Produktfarge:	Sølv
USB-strøm:	Ja
Støttede Windows operativsystemer:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	4
Plugg inn og spill:	Ja
Støttede Mac operativsystemer:	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Strømpluggtype:	Type A
Grensesnitt (hub):	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Overføringshastighet (Mbps):	5000 Mbit/s
