Side 1/20

USB to Fiber Optic Transceiver

Ethernet Adapters

Models: U336-1G-SFP (USB-A), U436-1G-SFP,

U436-SMF-1G-LC (USB-C)

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Quick Start Guide

WARRANTY REGISTRATION

to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 5 • Français 9 • Русский 13 • Deutsch 17

20-08-188.indb 120-08-188.indb 1 10/14/2020 6:03:01 PM10/14/2020 6:03:01 PM

U336-1G-SFP:

• Establishes a ﬁber optic Ethernet connection via the USB-A port on your

laptop, tablet or computer

• Features an open SFP port to connect a user-provided LC SFP transceiver

• Extends 1310 nm LC singlemode transmissions up to 5 kilometers or

1310 nm LC multimode transmissions up to 500 meters from your ﬁber

network without compromising speed or reliability

• Bus-powered via the USB-A port, so no external power is required

• Supports USB 3.0 speeds up to 5 Gbps

U436-1G-SFP:

• Establishes a ﬁber optic Ethernet connection via the USB-C™ port on

your laptop, tablet or computer

• Features an open SFP port to connect a user-provided LC SFP transceiver

• Extends 1310 nm LC singlemode transmissions up to 5 kilometers or

1310 nm LC Multimode transmissions up to 500 meters from your

ﬁber network without compromising speed or reliability

• Bus-powered via the USB-C port, so no external power is required

• Supports USB Type C speeds up to 5 Gbps

U436-SMF-1G-LC:

• Establishes a ﬁber optic Ethernet connection via the USB-C port on your

laptop, tablet or computer

• Built-in 1310 nm LC singlemode transceiver can be used to connect

to a ﬁber network at distances up to 5 kilometers

• Bus-powered via the USB-C port, so no external power is required

• Supports USB Type C speeds up to 5 Gbps

Product Features

20-08-188.indb 220-08-188.indb 2 10/14/2020 6:03:01 PM10/14/2020 6:03:01 PM

• U336-1G-LC, U436-1G-LC or U436-SMF-1G-LC USB to Fiber Optic

Ethernet Adapter

• Driver CD

• Quick Start Guide

• USB-A port (U336-1G-SFP) or USB-C port (U436-1G-SFP and

U436-SMF-1G-LC)

Note: Before installation, verify your ﬁber equipment’s wavelength

(1310 nm), mode type (single or multi) and distance (in meters)

matches that of the USB Fiber Transceiver Adapter speciﬁcations.

1. Install the applicable driver on your computer or laptop before

connecting the USB ﬁber transceiver adapter. The driver can be installed

using the included CD or by visiting the model’s Technical Support page

on tripplite.com to download.

2. Once the appropriate driver is successfully installed, connect a user-

supplied LC transceiver that is connected to a ﬁber network to the open

SFP port on the adapter. If using the U436-SMF-1G-LC, the transceiver

is already built into the unit and a separate transceiver is not needed.

3. If using the U336-1G-SFP, insert the USB-A male connector to a USB-A

port on your computer.

If using the U436-1G-SFP or U436-SMF-1G-LC, insert the USB-C male

connector to the USB-C port on your computer.

4. A blue LED will illuminate to indicate a successful Ethernet connection.

The LED will blink when data is being transferred.

Package Includes

System Requirements

Installation

20-08-188.indb 320-08-188.indb 3 10/14/2020 6:03:01 PM10/14/2020 6:03:01 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	netverkskort/adapter
Modell:	U436-1G-SFP
Vekt:	40 g
Bredde:	41 mm
Dybde:	56 mm
Høyde:	18 mm
LED-indikatorer:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Opprinnelsesland:	China
Pakkevekt:	120 g
USB-versjon:	3.2 Gen 1 (3.1 Gen 1)
Vertsgrensesnitt:	USB Type-C
Maksimal dataoverføringshastighet:	1000 Mbit/s
Komponent for:	Laptop
Fiberoptisk kontakt:	SFP
Produktfarge:	Hvit
Pakkedybde:	111 mm
Pakkehøyde:	39.1 mm
Pakkebredde:	157 mm
Driftstemperatur (T-T):	0 - 55 °C
Oppbevaringstemperaturomåde (Celsius):	0 - 60 °C
Harmonisert system (HS)-kode:	8517.62.0090
Ressurs-CD:	Ja
Relativ luftfuktighet under drift (H-H):	5 - 90
Videoopptaksgrensesnitt:	Fiber
Intern:	Nei
Guide for hurtiginstallering:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332256864
Masterkassens (ytterkassens) bruttovekt:	1200 g
Masterkassens (ytterkassens) lengde:	220 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	245.1 mm
Masterkassens (ytterkassens) høyde:	172 mm
Fibre Channel-porter:	1
Fibermodusstruktur:	Multi-mode, Single-mode
