Side 1/100

Triple-Display USB-C Docking

Station with International Power

Supply

Model: U442-DOCK8-BINT

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

and

USB-C

are registered trademarks of USB Implementers Forum.

Owner's Manual

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 21 • Français 41 • Русский 61 • Deutsch 81

• HDMI and DisplayPort connectors each support single-

monitor 4K applications up to 3840 x 2160 @ 60 Hz*

• Extends 1080p desktop image across 3 external screens at

the same time at resolutions up to 1920 x 1080 @ 30 Hz*

• Extends 1080p desktop image across 2 external screens at

the same time at resolutions up to 1920 x 1080 @ 60 Hz*

• RJ45 port supports true 10/100/1000 Mbps (1 Gbps) network

speeds when Wi-Fi is weak or unavailable

• USB-C PD 3.0 port supports 85W power output for charging

host device

• USB-A hub ports support USB 3.2 Gen 2 speeds up to

10 Gbps; one dedicated port supports up to 5V 1.5A (7.5W)

for charging mobile devices, 2.4A for Apple

devices

• USB-C hub port supports USB 3.2 Gen 2 speeds up to

10 Gbps for reading, writing and transferring data

• 3.5 mm microphone/speaker combo port supports

2.1-channel audio

• Plug-and-play operation with no software required for easy,

immediate installation

*Maximum resolution is determined by what your connected device can

support. See Cable Matrix for resolution breakdown.

Product Features

• U442-DOCK8-BINT

• USB-C to USB-C Cable, 1m (3.3 ft)

• External Power Supply with BS 1363 UK and CEE 7/8 EU

Power Cords

• Owner’s Manual

• N201-Series Cat6 Gigabit Snagless Patch Cables

• P312-Series 3.5 mm Mini Stereo Audio Cables

• P569-Series High-Speed HDMI Cables

• P580-Series DisplayPort Cables with Latches

• U420-Series USB 3.2 Gen 2 C/C Cables

• U428-Series USB 3.2 Gen 1 A/C Cables

• M100-Series USB Sync/Charge A/Lightning Cables

Package Contents

Optional Accessories

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	U442-DOCK8-BINT
Vekt:	250 g
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Opprinnelsesland:	China
Pakkevekt:	1500 g
Antall HDMI-porter:	1
Hodetelefonutganger:	1
HDCP:	Ja
HDMI-versjon:	2.0
Antall DisplayPorts:	2
Antall per pakke:	1 stykker
Utgangsstrøm:	20 V
Vertsgrensesnitt:	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
DisplayPort-versjon:	1.2
Auto MDI/MDI-X:	Nei
HDCP-versjon:	1.4/2.2
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Visningsmoduser:	Extended, Mirror
UASP-støtte:	Ja
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	144.8 mm
Pakkehøyde:	91.4 mm
Pakkebredde:	292.1 mm
Kabler inkludert:	USB Type-C til USB Type-C
Maksimal digital oppløsning:	3840 x 2160 piksler
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 70 °C
Lagringsrelativ fuktighet:	0 - 90
Bærekraftsertifikater:	REACH, RoHS, WEEE
Innebygd kortleser:	Nei
Harmonisert system (HS)-kode:	8517.62.0090
Kroppsmateriale:	Plast
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	1000 Mbit/s
USB-kabellengde:	1 m
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 90
AC-adapter bunt:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	2
HDR (High Dynamic Range) støttes:	Nei
Full tosidig:	Nei
Bærekraftsamsvar:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	3
Masterkassens (ytterkassens) bruttovekt:	15830 g
Masterkassens (ytterkassens) lengde:	304.8 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	475 mm
Masterkassens (ytterkassens) høyde:	315 mm
Innput-strøm:	2 A
USB Power Delivery:	Ja
USB Power Delivery opp til:	85 W
USB Type-C DisplayPort Alternate Mode:	Ja
USB Power Delivery-revisjon:	3.0
