Side 1/22

USB 3.1 Gen 1 to

HDMI Alternate Mode

Adapter

Models:

U444-06N-HD-AM, U444-06N-HDB-AM

Español 7 • Français 12 • Русский 17

Quick Start Guide

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

17-03-281-933753-EN-NEW.indd 1 3/26/2018 1:41:06 PM

Product Features

System Requirements

Package Contents

• USB-C or Thunderbolt™ 3 device that supports

USB DisplayPort Alternate Mode

• HDMI-enabled monitor

• U444-06N-HD-AM (White) or U444-06N-HDB-AM

(Black)

• Quick Start Guide

• Supports USB DisplayPort Alternate Mode for

displaying audio/video signals on an HDMI monitor

or projector via your computer, tablet, laptop or

smartphone’s USB-C™ or Thunderbolt™ 3 port

• Supports Ultra High Deﬁnition (UHD) 4K x 2K

video resolutions up to 3840 x 2160 (@ 30 Hz)

• Supports 36-bit Deep Color (12 bits per channel)

• Supports per-lane transfer rates of 5.4 Gbps

(HBR2), 2.7 Gbps (HBR) and 1.62 Gbps (RBR)

• Supports USB 3.1 Gen 1 data transfer rates up to

5 Gbps

• No external power supply or drivers required

USB Type-C™ and USB-C™ are trademarks of USB

Implementers Forum.

17-03-281-933753-EN-NEW.indd 2 3/26/2018 1:41:06 PM

Installation

1. Connect the adapter’s USB Type-C connector to

the USB Type-C port on your computer, tablet,

laptop or smartphone.

2. Connect the adapter’s HDMI port to a monitor

using an HDMI cable (such as Tripp Lite’s

P568-Series cables).

3. The video image will appear on the add-on

monitor. Use your device’s display settings to

customize how video is displayed on the add-on

monitor.

Speciﬁcations

Connectors

USB USB Type-C (Male)

Display HDMI (Female)

Video

Maximum Resolutions 3840 x 2160 (30 Hz)

Color Depth 36-bit Deep Color

(12 bits per channel)

Environmental

Operating Temperature 32° to 113°F (0° to 45°C)

Operating Humidity 10% to 85% RH,

Non-Condensing

Storage Temperature 14° to 158°F (-10° to 70°C)

Storage Humidity 5% to 90% RH,

Non-Condensing

Power Requirements

External Power Supply No

17-03-281-933753-EN-NEW.indd 3 3/26/2018 1:41:06 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U444-06N-HD-AM
Vekt:	20 g
Opprinnelsesland:	Vietnam
Pakkevekt:	30 g
Antall per pakke:	1 stykker
Tilkobling 1:	USB 3.1
Tilkobling 2:	HDMI
Dataoverføringshastighet:	5.4 Gbit/s
Produktfarge:	Hvit
Pakkedybde:	100.1 mm
Pakkehøyde:	20.1 mm
Pakkebredde:	119.9 mm
USB nødvendig:	Ja
Harmonisert system (HS)-kode:	84733020
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332189322
Masterkassens (ytterkassens) bruttovekt:	520 g
Masterkassens (ytterkassens) lengde:	119.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	255 mm
Masterkassens (ytterkassens) høyde:	115.1 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
Maksimum oppløsning (HDMI):	3840 x 2160 piksler
