Side 1/28

Owner’s Manual

USB 3.1 Gen 2 (10 Gbps)

USB Type-C to 2.5” SATA

SSD/HDD Enclosure

Model: U457-025-SATAG2

Español 8 • Français 15 • Русский 22

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

17-03-177-9336C8.indb 1 3/28/2017 9:32:46 AM

Package Contents

Product Features

• U457-025-SATAG2

• USB 3.1 Gen 2 (10 Gbps) Type-C Cable (M/M), 2 ft.

• Drive Mount Screws (x4)

• Enclosure Screws (x4)

• Screwdriver

• Rubber Feet

• Owner’s Manual

• Turn your 2.5” SATA Hard Disk Drive or Solid State Drive into a

portable external storage solution

• UASP-compatible for up to 70% faster performance when

connected to a UASP-enabled host controller

• Supports USB 3.1 Gen 2 data transfer rates up to 10 Gbps;

backward compatible with USB 3.0, 2.0 and 1.1

• Compliant with SATA III (6 Gbps), SATA II (3 Gbps) and SATA I

(1.5 Gbps) drives

• Tested with 2.5” SATA HDDs and SSDs up to 2 TB; will support

higher capacity drives when available

• Slim aluminum design provides durability and is perfect for travel;

tucks into laptop bag when not in use

• Aluminum housing with vents allows heat to dissipate and

passively cool the drive to help prevent drive failure and data loss

• Plug-and-play; no external power supply, software or drivers

required

17-03-177-9336C8.indb 2 3/28/2017 9:32:46 AM

System Requirements

Optional Accessories

• Computer with available USB Type-C port; USB 3.1 Gen 2

(10 Gbps) port required to achieve maximum speeds

• UASP-enabled host controller required to achieve UASP

performance

• 2.5” SATA HDD or SSD with 9.5 mm maximum height

• Compatible with all USB-enabled operating systems

• U420-003-G2 USB 3.1 Gen 2 (10 Gbps) Cable, USB Type-C

(M/M), 3 ft.

Powering the Unit

DC-In: In most cases, enough power is provided via the USB

computer connection. In the event additional power is needed, a

user-supplied power adapter can be used between the DC-In port on

the unit and a wall outlet.

Note: the U457-025-SATAG2 is compatible with 5V, 2A power supplies that

use a 3.5 x 1.3 x 8 mm output plug with a positive tip and negative sleeve.

17-03-177-9336C8.indb 3 3/28/2017 9:32:46 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	U457-025-SATAG2
Produkttype:	HDD/SSD-kabinett
Vekt:	150 g
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-C
Opprinnelsesland:	China
Pakkevekt:	150 g
Sertifisering:	CE, FCC
USB-versjon:	3.2 Gen 2 (3.1 Gen 2)
Materiale:	Aluminium
USB-tilkobling:	Ja
Produktfarge:	Sort
Antall USB-porter:	1
Pakkedybde:	128 mm
Pakkehøyde:	48 mm
Pakkebredde:	181.1 mm
Bærekraftsertifikater:	RoHS
Skruer inkludert:	Ja
Støttede lagringsgrensesnitt:	SATA
Antall lagringsdrivere som støttes:	1
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332202441
Masterkassens (ytterkassens) bruttovekt:	3350 g
Masterkassens (ytterkassens) lengde:	255 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	374.9 mm
Masterkassens (ytterkassens) høyde:	148.1 mm
Kjønn på USB-kontakt:	Hunkjønn
Lagringsstasjonens størrelse:	2.5 "
Skrutrekker inkludert:	Ja
