Side 1/36

Owner’s Manual

Component Video + Stereo

Audio over Cat5 Extenders

and Extender/Splitters

Extender Kit Models:

B136-101 and B136-101-WP-1

Extender/Splitter Local Unit Models:

B136-004

Extender Unit Models:

B136-100 and B136-100-WP-1

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

WARRANTY REGISTRATION

to win an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Español 13 • Français 25

Package Contents

Product Features

All Units:

• B136-004, B136-100, B136-100-WP-1,

B136-101 or B136-101-WP-1

• Owner’s Manual

B136-004 Only:

• External Power Supply (Input: 100-240V,

50/60 Hz, 0.5A Output: 5V 2A)

• 1 ft. Component + Audio Daisy-Chain Cable

B136-100-WP-1 and B136-101-WP-1 Only:

• Wallplate Hardware

• B136-004 works with a B136-100 or

B136-100-WP-1 to extend a component video

(1080i, 60 Hz) and stereo audio signal up to

300 ft. (91 m) from the source. Extend the signal

up to 400 ft. (121 m) using zero-skew cable

(Tripp Lite P524-01K).

• B136-101 and B136-101-WP-1 are kits that

come with units for both the source side and the

display side, allowing a component video (1080i,

60 Hz) and stereo audio signal to be extended up

to 300 ft. (91 m). Extend the signal up to 400 ft.

(121 m) using zero-skew cable (Tripp Lite

P524-01K).

Product Features

• Transmit a component video and stereo audio

signal to up to four A/V devices using the

B136-004 Extender/Splitter.

• Expand the number of connected A/V devices to up

to 13 (12 remote, one local) by daisy-chaining up

to three local units together.

• B136-004 features component video and stereo

audio ports for connecting an optional local A/V

device.

• Up to three B136-004 units can be connected to

a Tripp Lite B132-004-RB Rack-Mount Bracket

and mounted in just 1U of rack space.

• The B136-100, B136-100-WP-1, B136-101 and

B136-101-WP-1 require no external power.

• The B136-101-WP-1 and B136-100-WP-1

wallplates feature RJ45-type connectors, allowing

you to use standard patch cable and avoid 110

punchdown connections.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	USB Hub
Modell:	U460-004-2A2C-2
Vekt:	40 g
LED-indikatorer:	Ja
Minimum driftstemperatur:	0 °C
Opprinnelsesland:	China
Pakkevekt:	80 g
Sertifisering:	CE, FCC RoHS, REACH
Vertsgrensesnitt:	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Antall porter:	4
Kabellengde:	0.15 m
Produktfarge:	Sort
Pakkedybde:	80 mm
Pakkehøyde:	20 mm
Pakkebredde:	150 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 60 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	0 - 90
Harmonisert system (HS)-kode:	8517.62.0090
Kroppsmateriale:	Polyvinylklorid (PVC)
Relativ luftfuktighet under drift (H-H):	0 - 90
Plugg inn og spill:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	2
Grensesnitt (hub):	USB 3.2 Gen 2 (3.1 Gen 2) Type-A, USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Overføringshastighet (Mbps):	10000 Mbit/s
Maksimal opereringstemperatur:	60 °C
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	2
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332251715
Masterkassens (ytterkassens) bruttovekt:	1100 g
Masterkassens (ytterkassens) lengde:	165 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	230 mm
Masterkassens (ytterkassens) høyde:	100 mm
