Tripp Lite UPB-05K2-1U Bruksanvisning

Tripp Lite lader for mobile enheter UPB-05K2-1U

Les nedenfor 📖 manual på norsk for Tripp Lite UPB-05K2-1U (8 sider) i kategorien lader for mobile enheter. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/8

Owner’s Manual

5200mAh

Mobile Power Bank

Model: UPB-05K2-1U

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

15-06-037-933469-EN.indd 1 6/16/2015 11:06:46 AM

Product Features

Package Includes

System Requirements

Optional Accessories

• Charge your phone, tablet or other mobile device without the need for a

power outlet

• Sleek, low-proﬁle design is perfect for portable use

• USB port provides up to 5V, 1A of power for charging your mobile devices

• 5200mAh capacity charges devices at maximum power draw for hours

• Four battery-power LED indicators show remaining battery capacity

• Includes a built-in LED ﬂashlight

• Features short circuit, over-voltage, over-current, over-charge and over-

discharge protection for safe and reliable charging

• UPB-05K2-1U

• USB Micro-B Cable, 3 ft.

• Owner’s Manual

• A smartphone, tablet or other mobile USB device

• U030-Series USB 2.0 A to 5-Pin Mini-B Cables

• U038-Series USB 2.0 A to USB Type-C Cables

• UR05C-Series Micro-B Charge-Only Cables

• M100-Series USB 2.0 A to Lightning™ Cables

15-06-037-933469-EN.indd 2 6/16/2015 11:06:46 AM

USB Device Charging

Note:

• A button is located on the Mobile Power Bank next to the USB Micro-B input port.

When the button is pressed once, the LED indicators will illuminate to show how

much battery capacity is left. When pressed twice, the button turns the built-in LED

ﬂashlight on/off.

• When charging a USB device, the LED indicators on the Mobile Power Bank will

illuminate in one of four combinations to indicate the following battery capacity

levels:

• 75-100% Capacity – 4 LEDs illuminated solid

• 50-75% Capacity – 3 LEDs illuminated solid

• 25-50% Capacity – 2 LEDs illuminated solid

• 5-25% Capacity – 1 LED illuminated solid

• 0-5% Capacity – 0 LEDs illuminated

1. Connect your mobile device to the USB-A port on the Mobile Power

Bank using the included USB Micro-B cable or a USB cable suitable for

your device.

2. The device will begin charging with the LED indicator light(s) illuminating

according to the combinations listed above.

15-06-037-933469-EN.indd 3 6/16/2015 11:06:46 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lader for mobile enheter
Modell:	UPB-05K2-1U
Vekt:	118 g
Bredde:	45.72 mm
Dybde:	96.52 mm
Høyde:	22.86 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Batterikapasitet:	5200 mAh
Opprinnelsesland:	China
Pakkevekt:	270 g
Ladekilde:	USB
Utgangsstrøm:	5 V
Antall samtidig tilkoblede enheter (maks.):	1
Batteriteknologi:	Lithium-Ion (Li-Ion)
Produktfarge:	Sort
Pakkedybde:	149.9 mm
Pakkehøyde:	48.3 mm
Pakkebredde:	132.1 mm
Kabler inkludert:	Micro-USB
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Strømbeskyttelsesfunksjoner:	Over current, Over voltage, Overcharge, Overdischarge, Short circuit
Laderkompabilitet:	Universell
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332189377
Masterkassens (ytterkassens) bruttovekt:	2540 g
Masterkassens (ytterkassens) lengde:	287 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	246.4 mm
Masterkassens (ytterkassens) høyde:	172.7 mm
Innebygget lommelykt:	Ja
Inngangsgrensesnitt:	Micro-USB
USB A utgang:	1
Generell ladetid for enhet:	5.2 timer
