Side 1/8

TRUST 56K PCI MODEM

1. Introduction

This instruction manual is intended for the 'TRUST 56K PCI Modem’. This high-

speed, 56K PCI modem gives you a fast connection for Internet and e-mail use.

With the SuperVoice software, the Trust 56K PCI Modem is also ideal to use as a

handsfree telephone or a fax machine.

1.1 V92 standard

V92 is the future global standard devised by the ITU (International Telecom Union)

for communication between analogue modems. This improved standard is the

successor to the current V90 standard.

V92 is fully compatible with V90 and both standards have a download bandwidth of

56kbits/s. V92, however, has the following benefits:

• Improved data compression standard: V44 (V90 uses V42bis). This allows

for better data compression during data transfer, resulting in a higher

download speed. The increase in speed strongly depends of the nature of

the data being transferred: when downloading data that cannot be

compressed very easily, such as pictures in jpg format, the speed will equal

the speed achieved with V90.

• Increased upload speed (the maximum data transfer speed from your PC to

the Internet) to 48 kbit/s. V90 is limited to 33k6 bit/s.

• Faster 'connect time'. This is the time it takes to establish a full connection

with your ISP (Internet Service Provider). The technical name for this is V92

QuickConnect. This standard produces connect times of between 5 and 10

seconds.

• The 'modem standby' property. This property allows data communication to

be temporarily interrupted to accept incoming calls and to restart it after the

call has been ended.

At the time this manual was written, the V92 standard had not yet been issued. It is

expected to be ready in late October 2001, however, there may be some delay. As

soon as V92 becomes available, a firmware/driver update for the Trust 56K PCI

Modem will be placed on the Trust Internet site.

If you register your modem via www.trust.com/11709, you will be automatically

informed when the V92 firmware/driver is available.

Note: When the V92 standard is issued, it will probably take a few

months before your local ISP (Internet Service Provider) will

support the new standard. For further information, contact your

ISP.

Produkspesifikasjoner

Merke:	Trust
Kategori:	Ruter
Modell:	56K PCI Modem
Kompatible operativsystemer:	Win Windows 95, 98, ME, NT4, 2000
Minimum RAM:	16 MB
Minimum prosessor:	Pentium 166 MHz
Videoopptaksgrensesnitt:	PCI
Intern:	Ja
Plugg inn og spill:	Ja
Kompatibel med Mac:	Nei
Minstekrav til systemet:	4x CD-ROM
Modemshastighet:	56 Kbit/s
Modem (RJ-11)-porter:	1
