Table of Contents Rev. 12/9/2019 AHA MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Corp. Page 1 of 24
AHA-SERIES ALUMINUM ADJUSTABLE-HEIGHT GANTRY CRANE
I
NSTRUCTION MANUAL
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered, record a complete description of it on the bill of
lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply with
laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be
contacted online at http://www.vestilmfg.com/parts_info.htm.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Table of Contents Table of Figures
Specifications………...……………. 2, 3, 4 Fig. 1 AHA-2-8-8, 2-8-10, & 2-8-12 exploded view………………………….… 5
Signal Words……….…………....... 4 Fig. 2 AHA-2-10-8, 2-10-10, & 2-10-12 exploded view……………………….. 6
Safety Instructions……..…………... 4 Fig. 3 AHA-2-12-8, 2-12-10, & 2-12-12 exploded view……………………….. 7
Assembling the Crane..………….... 17, 18, 19, 20 Fig. 4 AHA-2-15-8, 2-15-10, & 2-15-12 exploded view………….…………….. 8
Using the Crane.............................. 21 Fig. 5 AHA-4-8-8, 4-8-10, & 4-8-12 exploded view………………………….… 9
Record of Satisfactory Condition..… 21, 22 Fig. 6 AHA-4-10-8, 4-10-10, & 4-10-12 exploded view………….…………….. 10
National Standards………………… 22 Fig. 7 AHA-4-12-8, 4-12-10, & 4-12-12 exploded view………….…………….. 11
Inspections & Maintenance ……….. 22 Fig. 8 AHA-4-15-8, 4-15-10, & 4-15-12 exploded view………….……………..
12
Labeling Diagram…………………… 23 Fig. 9 AHA-6-8-8, 6-8-10, & 6-8-12 exploded view……………………………. 13
Limited Warranty…………………… 24 Fig. 10 AHA-6-10-8, 6-10-10, & 6-10-12 exploded view…………….………… 14
Fig. 11 AHA-6-12-8, 6-12-10, & 6-12-12 exploded view…………….………… 15
Fig. 12 AHA-6-15-8, 6-15-10, & 6-15-12 exploded view…………….………… 16
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Website: www.vestilmfg.com e-Mail: HUinfo@vestil.comU
Table of Contents Rev. 12/9/2019 AHA MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Corp. Page 2 of 24
SPECIFICATIONS
Dimensions, net weight, and capacity information for each AHA-series crane is provided in the tables on pages 2,
3, and 4. However, minor changes in product design might alter specifications, particularly dimensions and net
weight. To provide instant access to up-to-date information, documents that provide specifications for AHA series
cranes are available online to anyone who visits the Vestil website. Acquire the appropriate specifications document
by opening this webpage: https://www.vestil.com/product.php?FID=522 . Click the “Specifications” tab. Scroll the
page to the entry for the specific model you purchased. Click the button in the “PDF” column that looks like a pencil
inside a blue-bordered box. A PDF file will open. This file is the specifications document. Print a copy of the document
as soon as your crane is delivered and keep it with your copy of this manual. If you encounter difficulties while trying
to obtain a copy of the specifications document, contact Technical Service. Contact information is provided on the
cover page of this manual.
Model
A:
Overall
width
B:
Overall
Beam
Length
C:
Usable
beam
length
D:
Beam
height
E:
Overall height
F:
Usable height
range
Capacity
Net
Weight
AHA-2-8-8
53
3
/
4
in.
136.5 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
6 in.
15.2 cm
(74-104) in.
(188-264.2) cm
(68 – 98) in.
(30.9 – 44.5) cm
2,000 lb.
909 kg
276 lb.
kg
AHA-2-8-10
53
3
/
4
in.
136.5 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
6 in.
15.2 cm
(98-128) in.
(249 - 325) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
277 lb.
kg
AHA-2-8-12
53
3
/
4
in.
136.5 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
6 in.
15.2 cm
(120 – 150) in.
(304.8 – 381) cm
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
287 lb.
kg
AHA-2-10-8
53
3
/
4
in.
136.5 cm
120 in.
304.8 cm
96
1
/
4
in.
244.5 cm
6 in.
15.2 cm
(74 – 104) in.
(188 – 264.2) cm
(68 – 98) in.
(172.7 – 248.9)cm
2,000 lb.
909 kg
272 lb.
kg
AHA-2-10-10
53
3
/
4
in.
136.5 cm
120 in.
304.8 cm
96
1
/
4
in.
244.5 cm
6 in.
15.2 cm
(98 – 128) in.
(248.9 – 325.1) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
293 lb.
kg
AHA-2-10-12
53
3
/
4
in.
136.5 cm
120 in.
304.8 cm
96
1
/
4
in.
244.5 cm
6 in.
15.2 cm
(120 – 150) in.
(304.8 – 381) cm
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
305 lb.
kg
AHA-2-12-8
53
13
/
16
in.
136.7 cm
144 in.
365.8 cm
120
1
/
4
in.
305.4 cm
8 in.
20.3 cm
(76 – 106) in.
(193 – 268.2) cm
(68 – 98) in.
(172.7 – 248.9) cm
2,000 lb.
909 kg
307 lb.
kg
AHA-2-12-10
53
13
/
16
in.
136.7 cm
144 in.
365.8 cm
120
1
/
4
in.
305.4 cm
8 in.
20.3 cm
(100 – 130) in.
(254 – 330.2) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
315 lb.
kg
AHA-2-12-12
53
13
/
16
in.
136.7 cm
144 in.
365.8 cm
120
1
/
4
in.
305.4 cm
8 in.
20.3 cm
(122 – 152) in.
(309.9 – 386.1) kg
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
327 lb.
kg
AHA-2-15-8
53
13
/
16
in.
136.7 cm
180 in.
457.2 cm
156
1
/
4
in.
396.9 kg
8 in.
20.3 cm
(76 – 106) in.
(193 – 269.2) cm
(68 – 98) in.
(172.7 – 248.9) cm
2,000 lb.
909 kg
360 lb.
kg
AHA-2-15-10
53
13
/
16
in.
136.7 cm
180 in.
457.2 cm
156
1
/
4
in.
396.9 kg
8 in.
20.3 cm
(100 – 130) in.
(254 – 330.2) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
405 lb.
kg
AHA-2-15-12
53
13
/
16
in.
136.7 cm
180 in.
457.2 cm
156
1
/
4
in.
396.9 kg
8 in.
20.3 cm
(122 – 152) in.
(309.9 – 386.1) kg
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
412 lb.
kg
AHA-4-8-8
53
15
/
16
in.
137 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
8 in.
20.3 cm
(76
1
/
8
– 106
1
/
8
) in.
(193.5 – 269.7) cm
(68
1
/
8
– 98
1
/
8
) in.
(173.2 – 249.4) cm
4,000 lb.
1,818 kg
353 lb.
kg
AHA-4-8-10
53
15
/
16
in.
137 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
8 in.
20.3 cm
(100
1
/
8
– 130
1
/
8
) in.
(254.3 – 330.5) cm
(92
1
/
8
– 122
1
/
8
) in.
(234 – 310.2) cm
4,000 lb.
1,818 kg
346 lb.
kg
AHA-4-8-12
53
15
/
16
in.
137 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
8 in.
20.3 cm
(122
1
/
8
– 152
1
/
8
) in.
(310.2 – 386.4) kg
(114
1
/
8
– 144
1
/
8
) in.
(289.9– 366.1) cm
4,000 lb.
1,818 kg
372 lb.
kg
A
B
C
D
E
F
