VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Web: www.vestilmfg.com e-mail: info@vestil.com
AIR-THL
P
NEUMATIC LOAD TILTER
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete
description of it on the bill of lading. If the product is undamaged, discard the packaging.
Notes: 1) The manufacturer continually develops all equipment and accessories. It reserves the right
to make changes to the models from time to time. No claims may be made based on the
information and illustrations contained in this manual. 2)
The end-user is solely responsible for
confirming that product design, use, and maintenance comply with laws, regulations, codes, and
mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The
Department can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-manuals.php.
REV I | 8/6/19
2
1. Introduction .................................................................................................................. 3
1.1 Using This Manual ....................................................................................................3
2. Description of Equipment .......................................................................................... 4
2.1 Specications ............................................................................................................ 4
3. Safety ............................................................................................................................. 5
3.1 User/Owner Responsibility ......................................................................................5
3.2 Safety Guidelines ...................................................................................................... 5
3.3 Material Safety ..........................................................................................................6
3.4 Energy Isolation ........................................................................................................ 6
4. Installation .................................................................................................................... 8
4.1 Pre-Shipment Planning ............................................................................................8
4.2 Inspection of Shipment .............................................................................................8
4.3 Installation Guidelines ..............................................................................................8
4.4 RetrotPackages ......................................................................................................9
5. Sequence of Operation .............................................................................................10
5.1 Operating Sequence ................................................................................................10
5.2 Foot Pedal Operation ..............................................................................................10
5.3 Hand Valve Operation .............................................................................................10
6. Maintenance ...............................................................................................................11
6.1 Considerations ........................................................................................................ 11
6.2 Maintenance Schedule ............................................................................................ 11
6.3 Airbag Replacement ...............................................................................................12
7. Caster Retrot Package ............................................................................................13
7.1 Installation ..............................................................................................................13
7.2 Operation ................................................................................................................14
8. Safety Ratchet Retrot Kit ........................................................................................ 15
8.1 Installation ..............................................................................................................15
9. Warranty ......................................................................................................................19
Contents
