APG-Series Adjustable Perimeter Guard System
Installation Manual
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of it on the bill of
lading and notify the freight carrier.
Notice:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the
product is used is the responsibility of the end-user.
2) VESTIL is not responsible for any injury or property damage that results from failure to apply either:
a) Instructions in this manual; or
b) Information provided in labels on the product.
Table of Contents Table of Figures
Specifications………………………………... 2 Fig. 1: Example Assembly………………………………………..…….. 3
Signal Words….……………………............. 2 Fig. 2 “Post and bracket”………………................................... ……... 3
Hazards of Improper Use…………………… 2 Fig. 3 “Cross-section of gate-hinge connection”….…………... ……... 4
Installation Instructions……………………… 3-5 Fig. 4 “Parts of hinge”…….……………………………………… ……... 4
Maintenance…………………………………. 5 Fig. 5 “Panel-to-post connections diagram
”……….................. ……... 5
Limited Warranty……………………………. 6
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail:
HU
info@vestil.com
U
9/6/2022 APG, MANUAL
Copyright 2022 Vestil Manufacturing Corp. Page 2 of 6
Signal Words:
This manual uses SIGNAL WORDS to call attention to uses of this product that are likely to result in personal injuries
or property damage. The signal words used in this manual appear below along with their definitions.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or SERIOUS
INJURY.
Identifies practices likely to result in product/property damage, such as operation that might damage the
product or other property.
Hazards of Improper Use:
Study the entire manual before using this cart. A copy of the manual should be available to users at all times. Read the
manual whenever necessary to refresh your understanding of the recommended operation, inspection, and maintenance
procedures.
Machine guards are used to reduce the likelihood that people might be injured by moving parts of
industrial equipment:
• ONLY use perimeter guards as a means for shielding people from machines.
• DO NOT use a structurally compromised perimeter guard system or component, i.e. panel and post. Examples of
structural damage include: broken or missing panel grid, broken or significantly bent post(s), and/or broken mounting
brackets. Inspect the perimeter guard according to the inspection instructions on p. 6. Replace a panel(s) or post(s)
that fails to pass any part of the inspection. DO NOT use the panel/post until authorized maintenance personnel either
approve the component for service, or replace the damaged component.
• DO NOT hang objects or material from the perimeter guard, or rest objects/material on the panels or posts.
• DO NOT modify a component in any way UNLESS you first obtain written approval from Vestil. Unauthorized
modifications might make a component unsafe to use or render it an ineffective barrier, which could result in operator
and/or bystander injury.
Model Description
Height in
Inches (~cm)
Width in
Inches (~cm)
Net Weight in
Pounds (~kg)
APG-M-35
Panel
36
60
28
APG-M-38
Panel
36
96
41
APG-M-45
Panel
48
60
34
APG-M-48
Panel
48
96
50
APG-M-55
Panel
60
60
40
APG-M-58
Panel
60
96
59
APG-M-65
Panel
72
60
46
APG-M-85
Panel
96
60
59
APG-P6-L
Post
72
N/A
16
APG-P6-C
Corner post
72
N/A
21
APG-P8-L
Post
96
N/A
20
APG-P8-C
Corner post
96
N/A
25
APG-DR-54
Hinged door
60
48
73
Specifications:
Thank you for purchasing an APG-series Adjustable Perimeter Guard System from
Vestil Manufacturing
Corporation (“Vestil”). Our perimeter guards are durable, high-quality products engineered to be both dependable and
uncomplicated. Any person who might install or maintain this product should be familiar with the instructions provided in
this manual.
Dimensions and other product specifications appear in the following table:
