Side 1/10
Table of Contents Rev. 4/25/2025 CR, MANUAL
Table of Contents Copyright 2025 Vestil Manufacturing Page 1 of 10
CR-series Carpet Poles
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it
on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also
be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Vestil Manufacturing Company
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestil.com e-mail: info@vestil.com
Table of Contents
Page
Signal Words….…………………………………………………………….………..…………………………………
2
Safety Instructions.………………………………………………………………..……..……………………………
2
Specifications……………...……………………………..……………………………………………………………
3
CR (class 2 carriage) Exploded View & Bill of Materials……………..…………………...............................
4
CR (class 3 carriage) Exploded View & Bill of Materials…..…………..…………………….…………………
5
Attaching the Carpet Pole to a Lift Truck Carriage……………….…………………………...……………...
6
National Standards……………………………………………………………………………………………………
7
Using the Carpet Pole…………...……………………………………………………...……………………………
7
Record of Satisfactory Condition…………………………………………………………………………………..
7
Inspecting the Carpet Pole…..…………………………………...…………………………………………...……
7 - 8
Maintaining the Carpet Pole………..……………………………………………………………………...………
8
Labeling Diagram……...…………………………………………………………………………..……………...…
9
Limited Warranty…...…………………………………………………………………………...…………….………
10
Table of Contents Rev. 4/25/2025 CR, MANUAL
Table of Contents Copyright 2025 Vestil Manufacturing Page 2 of 10
SIGNAL WORDS
SIGNAL WORDS appear in this manual to draw the reader’s attention to important safety-related
messages. The following are signal words used in this manual and their definitions.
SAFETY INSTRUCTIONS
Vestil strives to identify foreseeable hazards associated with the use of its products, but no manual can
address every conceivable risk. Minimize the likelihood of injury by observing the hazards identified below
and by inspecting and maintaining the product as instructed in the INSPECTIONS and MAINTENANCE
sections of this manual on p. 6-7.
WARNING
Risks of serious personal injuries or death. Always apply material handling techniques learned during
training and use the product properly.
Read and understand the entire manual before assembling, using or servicing the product.
Before using this (forklift) front end attachment, you must contact the manufacturers of all forklifts that
will use it to request: 1) written approval; and 2) markings for each forklift that identify the coil carrier AND
give the approximate weight of the forklift and carrier at maximum elevation with a laterally-centered
load. DO NOT use the carpet pole until all forklifts are appropriately marked.
Read and understand the entire manual before installing, using, or servicing the product. Read the
manual to refresh your understanding of proper use, inspection, and maintenance procedures whenever
necessary.
DO NOT exceed the capacity of your unit. See LABELING DIAGRAM, label 1153, p. 9.
Inspect the carpet pole before each use as described in INSPECTING THE CARPET POLE on p. 7-8.
Before attaching the carpet pole to the carriage of your fork lift, inspect the carriage and confirm that
all parts are structurally sound and in satisfactory condition. See RECORD OF SATISFACTORY CONDITION
on p. 6.
Always connect the safety chain to the carriage of your forklift without slack. The unit must not be able
to slide on the forks.
Verify that the load is stable by lifting the carpet just a few inches above the ground. Load swing
should be minimal and the carpet pole should not shift on the forks. If the load is not stable while
elevated, return it to the ground and use another device to transport it.
ALWAYS apply the rules governing use of (forklift) front end attachments applied at your work site.
DO NOT cover or remove any label. Verify the location and legibility of all labels. Label placement is
shown in the LABELING DIAGRAM on p. 9. DO NOT use this device UNLESS all product labels are readable
and undamaged.
DO NOT ride or sit on the carpet pole.
DO NOT use the carpet pole to push objects. Only use the product to transport a roll of carpet.
ONLY use this product when traveling on firm, level, even ground.
Carpet roll must not be longer than the pole. The carpet roll must not hang over the end of the pole.
See USING THE CARPET POLE on p. 7 for loading instructions.
DO NOT leave elevated rolls of carpet unattended. Always lower the load to the ground before
leaving the forklift.
DO NOT modify the carpet pole in any way UNLESS you first obtain written approval from Vestil.
Unauthorized modifications automatically void the LIMITED WARRANTY (p. 10) and might make the
product unsafe to use.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
NOTICE
Identifies practices likely to result in product/property damage, such as operation
that might damage the product.
