Side 1/13
Table of Contents Rev. 12.6.2018 LAD-MM, MANUAL
Table of Contents C
opyright 2017 Vestil Manufacturing Co. Page 1 of 13
LAD-MM Series Mobile Ladder Stands
Instruction Manual
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether
it sustained damage during transport. If damage is discovered, record a complete description of it on the
bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Assistance:
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can
also be contacted online at http://www.vestilmfg.com/parts_info.htm
.
Table of Contents
Specifications…………..…………………….………………………………………………………………………..…. 2
Signal Words………….……................................................................................................................................ 3
Hazards of Using the Ladder………………………..………………………………………………………………….. 3
Exploded Views and Bills of Materials…..……………………………………………………………..................4 – 8
LAD-MM-(2; 3; & 4)-(P & G)…………………………………………………………………………………………. 4
LAD-MM-(5; 6; & 7)-(P & G)…………………………………………………………………………………………. 5
LAD-MM-(8; 9; & 10)-(P &G)………………………………………………………………………………………… 6
LAD-MM-11-(P & G)………………………………………………………………………………………………….. 7
LAD-MM-12-(P & G)………………………………………………………………………………………………….. 8
Assembling the Ladder…..………………………………………………………………………………………9, 10, 11
Using the Ladder……..…………..…………………………………………………………………………………….. 11
Record of Normal Condition…………………………………………………………………………………………… 12
Inspections & Maintenance…………................................................................................................................. 12
Labeling Diagram………...…............................................................................................................................. 12
Limited Warranty…………...…………………………………………………………………………………………… 13
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com Email: info@vestil.com
Table of Contents Rev. 12.6.2018 LAD-MM, MANUAL
Table of Contents C
opyright 2017 Vestil Manufacturing Co. Page 2 of 13
Specifications:
Dimensions and other relevant specifications for each LAD-MM series ladder stand appear in the table
below.
Model
Number of
steps
A:
Overall
height
B:
Overall
width
C:
Railing
height
D:
Platform
height
E:
Usable
length
F:
Overall
length
Step
slope
Capacity
Net
Weight
LAD-MM-2-P
2
50”
29
1
/
2
”
30”
20”
27
1
/
4
”
38
1
/
2
”
58°
350 lb.
69 lb.
LAD-MM-3-P
3 60” 29
1
/
2
” 30” 30” 33
1
/
2
” 38
7
/
16
” 58° 350 lb. 82 lb.
LAD-MM-4-P
4
70”
29
1
/
2
”
30”
40”
39
3
/
4
”
42
5
/
8
”
58°
350 lb.
100 lb.
LAD-MM-5-P
5 80” 29
1
/
2
” 30” 50” 46” 49
3
/
4
” 58° 350 lb. 119 lb.
LAD-MM-6-P
6
90”
29
1
/
2
”
30”
60”
52
1
/
4
”
56
11
/
16
”
58°
350 lb.
135 lb.
LAD-MM-7-P 7 100” 29
1
/
2
” 30” 70” 58
1
/
2
” 62
3
/
8
” 58° 350 lb. 150 lb.
LAD-MM-8-P
8 110” 29
1
/
2
” 30” 80” 64
3
/
4
” 68
5
/
8
” 58° 350 lb. 169 lb.
LAD-MM-9-P
9 120” 29
1
/
2
” 30” 90” 71” 74
7
/
8
” 58° 350 lb. 185 lb.
LAD-MM-10-P
10 130” 29
1
/
2
” 30” 100” 77
1
/
4
” 81
1
/
8
” 58° 350 lb. 202 lb.
LAD-MM-11-P
11
140”
32”
30”
110”
83
1
/
2
”
87
3
/
8
”
58°
350 lb.
222 lb.
LAD-MM-12-P
12 156” 32” 36” 120” 89
3
/
4
” 93
1
/
4
” 58° 350 lb. 247 lb.
LAD-MM-2-G
2
50”
29
1
/
2
”
30”
20”
27
1
/
4
”
38
1
/
2
”
58°
350 lb.
70 lb.
LAD-MM-3-G
3 60” 29
1
/
2
” 30” 30” 33
1
/
2
” 38
1
/
2
” 58° 350 lb. 84 lb.
LAD-MM-4-G
4
70”
29
1
/
2
”
30”
40”
39
3
/
4
”
43
5
/
8
”
58°
350 lb.
101 lb.
LAD-MM-5-G 5 80” 29
1
/
2
” 30” 50” 46” 49
3
/
4
” 58° 350 lb. 121 lb.
LAD-MM-6-G
6 90” 29
1
/
2
” 30” 60” 52
1
/
4
” 56
11
/
16
” 58° 350 lb. 137 lb.
LAD-MM-7-G 7 100” 29
1
/
2
” 30” 70” 58
1
/
2
” 62
3
/
8
” 58° 350 lb. 152 lb.
LAD-MM-8-G
8 110” 29
1
/
2
” 30” 80” 64
3
/
4
” 68
5
/
8
” 58° 350 lb. 172 lb.
LAD-MM-9-G
9 120” 29
1
/
2
” 30” 90” 71” 74
7
/
8
” 58° 350 lb. 188 lb.
LAD-MM-10-G
10 130” 29
1
/
2
” 30” 100” 77
1
/
4
” 81
1
/
8
” 58° 350 lb. 205 lb.
LAD-RF-11-G
11
140”
32”
30”
110”
83
1
/
2
”
87
3
/
8
”
58°
350 lb.
225 lb.
LAD-RF-12-G
12 156” 32” 36” 120” 89
3
/
4
” 93
1
/
4
” 58° 350 lb. 250 lb.
Table of Contents Rev. 12.6.2018 LAD-MM, MANUAL
Table of Contents C
opyright 2017 Vestil Manufacturing Co. Page 3 of 13
Signal words:
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call attention to uses
of the product likely cause property damage. The signal words used appear below along with the meaning of each word:
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the crane.
Hazards of Using the Ladder:
Vestil strives to identify foreseeable hazards associated with the use of its products. However, no manual can
address every conceivable risk. The most effective way to avoid injury from misusing this product is to exercise sound
judgment whenever the ladder is in use
.
If this product is used improperly or carelessly, the user and/or bystanders might sustain serious personal
injuries or could even be killed. ALWAYS use the product properly:
• Read and understand the entire manual before assembling, using or servicing the ladder.
• DO NOT exceed the rated load of the ladder. The total weight applied to the ladder (weight of the user plus tools, etc.)
must not be greater than the rated load.
• DO NOT use the ladder on uneven or unstable surfaces. ONLY use the ladder on level, even surfaces
• Make sure that you will not contact overhead objects with either your body or with the ladder during use.
• Always unload the ladder before leaving it unattended.
• Remove foreign matter, like mud or grease, from your shoes before walking on the ladder.
• ALWAYS face the stairs and use the handrails while ascending and descending the ladder.
• DO NOT increase the height of the platform or of a step by standing on other objects placed on the ladder.
• Inspect the ladder as described in Inspections & Maintenance on p. 12. DO NOT use the ladder unless it is in normal
condition. ONLY use manufacturer-approved replacement parts if repairs are necessary.
• DO NOT use the ladder if the caps on the front legs are significantly worn. See applicable Exploded View on p. 4-8.
Caps should prevent the ladder from sliding. If either or both caps are too worn to function properly, replace them
before using the ladder again.
• ONLY use the ladder to access objects that you cannot otherwise reach. DO NOT use the ladder for any other
purpose. For instance, DO NOT use the ladder as a storage rack or as a way to move people or material. Always
unload the ladder before leaving it unattended.
• DO NOT lean or reach over the sides of the ladder. Position the ladder as close to the work as possible.
• DO NOT attempt to move the ladder while someone is using it.
• DO NOT use the ladder to transport people or objects.
• DO NOT remove or obscure any label. Each label must be readable, undamaged, and present in the appropriate
location. See Labeling diagram on p. 12.
• DO NOT modify this ladder! Unauthorized modifications automatically void the Limited Warranty (p. 13) and might
make the ladder unsafe to use.
This product must be properly maintained to function properly. See Inspections & Maintenance on p. 12.
• Keep the ladder clean & dry.
• Periodically check the ladder frame. The ladder should be solid, square, and free of rust and corrosion.
• Lubricate the wheel bolts whenever necessary for the wheels to rotate freely.
• The ladder stand is designed for both indoor and outdoor use. However, it should be stored indoors when not in use.
