Side 1/24
PRODUCT MANUAL
Designed, Manufactured and Supported in the USA
SECURITY & COMMUNICATION SOLUTIONS
VIKING
Features
Specifications
www.VikingElectronics.com
• SIP compliant (see page two for list of compatible SIP servers and IP phone systems)
• Outbound Proxy, Authentification ID, Per to Peer, VLAN Tagging
• PoE powered (class 3, <13 Watts)
• Up to 28 second ID announcement (uploaded from wave file or recorded live)
• Paging prioritization
• Plays audio from multicast
• SIP endpoint or multicast group member
• Supports up to 10 multicast paging groups
• Add an optional SL-2 blue, green, red or amber strobe light (see DOD 242)
• Blue call status LED indicator
• Automatic Noise Canceling (ANC) feature for operation in noisy environments
• Viking’s proprietary VOX switching eliminates the need for “Push to Talk” mode
• Selectable auto-answer feature for monitoring
• Built-in high efficiency 6 Watt class D amplifier
Power: PoE class 3 (<13 Watts)
Dimensions: 23.75” x 23.75” x 3.75” (603.25mm x 603.25mm x 95.25mm)
Shipping Weight: 8.6 lbs (3.91 kg)
Operating Temperature: -40°F to 140°F (-40° C to 60° C)
Humidity: 5% to 95% non-condensing
Audio Codecs: G711u, G722* and G711a*
Network Compliance:
IEEE 802.3 af PoE, SIP 2.0 RFC3261, 100BASE-TX with auto cross over
Regulatory Compliance: CE, FCC Part 15 and Canada ICES-003 Class A
Sensitivity: 96dB / 1W / 1M S.P. Level
Maximum Output Level: 105 dB SPL @ 1M (with no additional Speakers connected)
Amplifier: 6 Watt class D
Connections: (1) RJ45 10/100 Base-T
*NOTE: The 22TB-IP does not support multicast paging using the G722 or G711a Codec.
The Viking model 22TB-IP Talk-Back 2 x 2 ceiling tile replacement
speaker enables two-way conversations and end point paging via
SIP, yet also allows for standard paging and background music via
multicast. The Talk-Back Speaker easily connects with a single
CAT5/6 cable from your PoE switch. Its 2’ x 2’ size, shallow depth
and light weight design make for a quick and easy installation in
drop/suspended ceilings. The speaker’s aesthetically pleasing white
grill blends in with existing ceiling tiles and air vents.
An auxiliary switch input allows for a hard wired wall mounted button
to initiate a SIP call. A momentary button press will initiate a
standard call, and holding the button for 3 or more seconds will
initiate an emergency call. The integrated high sensitivity
microphone enables talk-back and also monitors room noise to
automatically increase the speaker volume when necessary. Line
level audio output connections are provided for connecting to an
external amplifier. The 22TB-IP has an integrated 6 watt amplifier
allowing its speaker output connections to directly drive up to 5
additional analog speakers. A programmable relay output is
• Can drive up to 5 external analog speakers for greater coverage
• Relay for activating door locks, strobe lights, external amplifiers, etc.
• SIP/Multicast: SIP page, SIP page and zoned multicast stream, zoned multicast receive
• Support for access code to prevent unwanted SIP calls
• Line-level audio output for connecting to an external amplifier
• Hangs up on: busy signal, time-out, or touch tone command
• Network remote speaker volume control
• Mounting: Drop mounts into 2 p1-x2 or 2 x 4 suspended ceilings
• Heavy duty back box protects speaker and circuitry against plenum dust
• Automatic Gain Control (AGC) to automatically increase ring volume to compensate for
ambient noise
• Diagnostics for testing microphone, speaker and relay
• Programmable pre page alert tone
• Amplified SIP endpoint or multicast IP paging for: schools, hospitals,
retail stores, office spaces, etc.
• Provide background music and sound masking
• Make standard and/or emergency SIP phone calls via hands free
talkback speaker
• Background music and emergency calls for elevator applications
retail stores, office spaces, etc.
22TB-IP
Ceiling Tile SIP/Multicast
Talk-Back Speaker
October 7, 2019
2 x 2 Drop-In Ceiling Tile IP Speaker for SIP Endpoint or Multicast
Paging and Making Standard and / or Emergency SIP Calls
Applications
Installation requires a Network Administrator / IT Technician
!
Model 22TB-IP
provided for activating door locks, strobe lights, external amplifiers,
etc. A programmable blue status LED is provided to indicate paging,
SIP call and network registration.
2
VoIP SIP System Compatibility
For compatibility and vendor specific detailed configuration instructions, see the Viking VoIP
SIP System Compatibility List, DOD 944. To open and download this PDF file:
1. Go to www.vikingelectronics.com
and enter 944 in the search box
2. Click Application Note (DOD 944)
to open and download the PDF
Scan the QR code below to open
and download the Viking VoIP
SIP System Compatibility List
- OR -
Important: Exclusion from this list means only that compatibility has not been verified, it does not mean
incompatibility. If you have questions, please call Viking Electronics at 715-386-8861.
3
Definitions
Client: A computer or device that makes use of a server. As an example, the client might request a particular file from the server.
DHCP: Dynamic Host Configuration Protocol. In this procedure the network server or router takes note of a client’s MAC address and
assigns an IP address to allow the client to communicate with other devices on the network.
DNS Server: A DNS (Domain Name System) server translates domain names (ie: www.vikingelectronics.com) into an IP address.
Ethernet: Ethernet is the most commonly used LAN
technology. An Ethernet Local Area Network typically uses twisted pair wires to
achieve transmission speeds up to 1Gbps.
Host: A computer or device connected to a network.
Host Name: A host name is a label assigned to a device connected to a computer network that is used to identify the device in various
forms of network communication.
Hosts File: A file stored in a computer that lists host names and their corresponding IP addresses with the purpose of mapping addresses
to hosts or vice versa.
Internet: A worldwide system of computer networks running on IP
protocol which can be accessed by individual computers or networks.
IP: Internet Protocol is the set of communications conventions that govern the way computers communicate on networks and on the
Internet
.
IP Address: This is the address that uniquely identifies a host on a network.
LAN: Local Area Network. A LAN is a network connecting computers and other devices within an office or building.
Lease: The amount of time a DHCP
server reserves an address it has assigned. If the address isn’t used by the host for a period of
time, the lease can expire and the address can be assigned to another host.
MAC Address: MAC stands for Media Access Control. A MAC address, also called a hardware address or physical address, is a unique
address assigned to a device at the factory. It resides in the device’s memory and is used by routers to send network traffic to the correct
IP address. You can find the MAC address of your 22TB-IP speaker printed on a white label just above the PoE LAN port (see page 4).
Router: A device that forwards data from one network to another. In order to send information to the right location, routers look at IP
Address, MAC Address and Subnet Mask.
RTP: Real-Time Transport Protocol is an Internet protocol standard that specifies a way for programs to manage the real-time transmission
of multimedia data over either unicast or multicast network services.
Server: A computer or device that fulfills requests from a client. This could involve the server sending a particular file requested by the
client.
Session Initiation Protocol (SIP): Is a signaling communications protocol, widely used for controlling multimedia communication sessions
such as voice and video calls over Internet Protocol (IP
) networks. The protocol defines the messages that are sent between endpoints,
which govern establishment, termination and other essential elements of a call.
Static IP Address: A static IP Address has been assigned manually and is permanent until it is manually removed. It is not subject to the
Lease
limitations of a Dynamic IP Address assigned by the DHCP Server. The default static IP Address is: 192.168.154.1
Subnet: A portion of a network that shares a common address component. On TCP/IP networks, subnets are defined as all devices
whose IP addresses have the same prefix. For example, all devices with IP addresses
that start with 100.100.100. would be part of the
same subnet. Dividing a network into subnets is useful for both security and performance reasons. IP networks are divided using a subnet
mask.
TCP/IP: Transmission Control Protocol/Internet Protocol is the suite of communications protocols used to connect hosts on the Internet.
TCP/IP uses several protocols, the two main ones being TCP and IP. TCP/IP is built into the UNIX operating system and is used by the
Internet, making it the de facto standard for transmitting data over networks.
TISP: Telephone Internet Service Provider
WAN: Wide Area Network. A WAN is a network comprising a large geographical area like a state or country. The largest WAN is the
Internet
.
Wireless Access Point (AP): A device that allows wireless devices to connect to a wired network using Wi-Fi, or related standards. The
AP usually connects to a router (via a wired network) as a standalone device, but it can also be an integral component of the router itself.
Wireless Repeater (Wireless Range Extender): takes an existing signal from a wireless router or access point and rebroadcasts it to
create a second network. When two or more hosts have to be connected with one another over the IEEE 802.11 protocol and the distance
is too long for a direct connection to be established, a wireless repeater is used to bridge the gap.
