Side 1/13
PRODUCT MANUAL
RIFLESCOPE
STRIKE EAGLE
®
3 2
STRIKE EAGLE
®
Configuration 5-25x56
Waterproof Yes
Fogproof Nitrogen gas purged
Length 14.6" (370.8 mm)
Mounting Length 4.6" (116.84mm)
Weight 30.4 oz. (w/o battery)
Eye Relief 3.66" (93 mm)
Field of View 5x = 22' @ 100 yds (4.2°)
25x = 7.3' @ 100 yds (1.4°)
Battery CR2032
SPECIFICATIONS
Strike Eagle
®
MOA MRAD
Adjustment Graduation 1/4 MOA 0.1 MRAD
Elevation Adjustment
with Zero Stop
without Zero Stop
47 MOA
110 MOA
18 MRAD
31 MRAD
Windage Adjustment 78 MOA 23 MRAD
Travel Per Rotation 25 MOA 10 MRAD
When you’re ready to step up your long-distance game,
the Strike Eagle
®
gives you more of the tools you need for
less than you’d expect. Start with an XD
™
Optical System
for crystal clear, edge-to-edge sharpness, and add a First
Focal Plane (FFP) illuminated reticle for fast reads at any
magnification, and any lighting situation. Throw in a locking
zero stop Elevation Turret and locking Windage Turret and
you’ve got a long-distance impact machine that’ll have you
wondering how you ever shot without it.
Understanding the Controls
Images are for representation only. Product may vary slightly from what is shown.
1
Eyepiece/
Ocular Lens
2
Reticle Focus
3
Locking Elevation Turret
4
Parallax Adjustment
Knob/ Side Focus Knob
5
Illumination
Control Knob
6
Objective Lens
7
Windage Turret
8
Magnification
Adjustment Ring
9
Throw Lever
10
Zero Stop Ring
(Eyepiece)(Objective Bell)
Lengths L1 L2 L3 L4
14.6" 2.0" 2.6" 6.4"
Heights H1 H2
2.52" 1.84"
H2
L2
L4
L1
L3
H1
1
2
8
3
4
5
6
7
9
10
THE STRIKE EAGLE
®
RIFLESCOPES
