VXi D200 Dialpad
Warranty
1. VXi warrants that your D200 Dialpad will be free from defects in mate-
rial and workmanship for one year from the date of purchase. If, during
the rst year from the date of purchase, your D200 Dialpad fails to work
due to a defect in material or workmanship, VXi will repair or replace the
product, at its election, free of charge. Without proof of purchase, the
warranty period begins on the date of manufacture.
2. The foregoing limited warranty does not cover equipment failure at-
tributable to accident, improper operation, misuse, abuse, or any cause
other than defects in the materials or workmanship of VXi’s products.
3. VXi’s obligations under this warranty are limited to repair or replace-
ment (at our option) of any defective part returned to VXi at the cus-
tomer’s expense. Returned products require a Return Authorization that
may be obtained by calling 1-800-742-8588. Products returned to VXi for
repair under this warranty will be return shipped to the customer at VXi’s
expense.
4. THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some jurisdic-
tions do not permit the exclusion of implied warranties and the forego-
ing exclusions may not apply to you.
5. In no event shall VXi be responsible for any other damages whatsoever,
including direct, indirect, special, incidental, consequential, or other
damages for breach of this or any other warranty, express or implied.
271 Locust Street • Dover, NH 03820 USA • 800-742-8588 • 603-742-2888
www.vxicorp.com ©VXi Corporation 2010 PN202933B Printed in China Connecting to the world.you
H I J K L
5 2 Operation Features
E
A
B
C
D
F
G
M N O P
A. In Use/Ringer LED
B. Mute LED
C. Redial
D. Pause
E. On/O
F. Flash
G. Mute
H. Telephone line jack
I. Extension jack
J. Ring setting
K. Flash Setting
L. Mode setting
M. Headset jack
N. Recording jack
O. Speaker volume
P. Microphone volume
REDIAL
1) Press On/O button
2) Press REDIAL button to automatically dial the last num-
ber dialed. If your phone requires you to dial 0 or 9 to get an
outside line, you may not be able to use the redial feature.
MUTE / UNMUTE
To mute your voice while on a call, press the MUTE but-
ton once. The MUTE LED will light. To unmute, press the
MUTE button again.
PAUSE
Use the PAUSE button to pause after dialing an access
number (such as 9) and the telephone number, and for
certain banking and long-distance services.
CALL WAITING
To answer a call through call waiting, press the FLASH
button once. To return to the rst call press FLASH again.
TRANSFER A CALL
To transfer a call, press FLASH then dial the phone num-
ber of the person to whom the call is being transferred.
When the person answers, press ON/OFF to hang up. If
the call is disconnected before it transfers, adjust the FLASH
settings (see Section 6-Operation).
1 Introduction 6 Operation
Thank you for choosing the VXi D200 Dialpad. RINGER SETTINGS
To adjust the volume of the ringer, set the RING switch
to the HI (H) or LOW (L) position. To turn the ringer o,
set the switch to the OFF (A) position.
FLASH SETTINGS
Set the switch to either A or B to enable the dialpad to
transfer calls.
MODE SETTINGS
If you have a touch tone phone, set the switch to “T”.
If you have a rotary phone, set the switch to “P”.
REC JACK (optional use)
This port can be used to connect a recording device for
call monitoring purposes. It is also possible to connect
a second headset with a 2.5mm plug, although it is
recommended to use a single headset.
EXT JACK (optional use)
The D200 Dialpad is a fully functioning telephone;
however, it is possible to connect the dialpad to a sec-
ond phone with an RJ-11 cord, if desired (not included).
Line CordD200 Dialpad
Headset Hook (Attach to side
of computer to hang the
headset when not in use.)
Included in the box:
