Side 1/71

Contents

Index

User’s Manual

About the Cintiq Companion

Getting Started

Customizing your Cintiq

Pen features

The multi-touch experience

The Wacom Desktop Center

Troubleshooting

Care and maintenance

Support options

Professional Creative Tablet

Contents Index

Contents

Index

Cintiq Companion

User’s Manual

Version 1.0, Rev H0413

Wacom reserves the right to revise this publication without obligation to provide notification of such changes.

Wacom does its best to provide current and accurate information in this manual. However, Wacom reserves the right

to change any specifications and product configurations at its discretion, without prior notice and without obligation

to include such changes in this manual.

The above year indicates when this manual was prepared. However, the date of release to the users of the manual is

simultaneous with the introduction into the market of the applicable Wacom product.

Cintiq and Wacom are registered trademarks of Wacom Co., Ltd.

Adobe and Photoshop are either registered trademarks or trademarks of Adobe Systems Incorporated in the United

States and/or other countries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft

Corporation in the United States and/or other countries.

Any additional company and product names mentioned in this documentation may be trademarked and/or registered

as trademarks. Mention of third-party products is for informational purposes only and constitutes neither an

endorsement nor a recommendation. Wacom assumes no responsibility with regard to the performance or use of

these products.

ExpressKey is a registered trademark of Ginsan Industries, Inc., and is used with permission.

Front cover image courtesy of www.daniellieske.com

Contents Index

Contents

Index

TABLE OF CONTENTS

ABOUT THE MANUAL 4

ABOUT THE CINTIQ COMPANION 5

Features 5

Parts and Accessories 6

Unpacking 6

Front view 7

Rear and side views 8

Adjusting the stand 9

Operating System 10

Battery status and Operation 10

GETTING STARTED 11

Setting up your work area 12

The Wacom Desktop Center 12

Pen features 15

Using the pen 16

Holding the pen 16

Positioning 17

Clicking 17

Erasing 17

Dragging 17

Side switch 17

Working with pressure sensitivity 17

Drawing with tilt 17

Pen and digital ink capabilities in Windows 18

Using the ExpressKeys, Rocker Ring, and

Windows Button 19

The multi-touch experience 20

Navigating with multi-touch 20

Customizing multi-touch 20

Setting multi-touch options 21

Testing multi-touch 22

Working with multiple monitors 22

Customizing your Cintiq 23

Viewing Settings and Express View 23

Control panel overview 24

Calibrating the Cintiq 26

Customizing the pen 27

On-Screen Controls 33

Creating Screen Keys or Screen Touch Strips 33

Customizing Screen Keys or

Screen Touch Strips 35

Assigning Panels to ExpressKeys or Rocker Ring

buttons 35

Using Screen Keys or Screen Touch Strips 37

Changing the appearance of on-screen controls 37

Managing On-Screen Controls 37

Button functions 38

Using and customizing the Radial Menu 45

Application-specific settings 46

Creating an application-specific setting 47

Changing application-specific settings 48

Removing application-specific settings 48

Working with multiple tools 48

Renaming the tablet in the tablet list 48

TROUBLESHOOTING 49

General Function 49

Testing controls and input tools 49

Testing the ExpressKeys and Rocker Ring 51

Testing a pen 5 1

General problems 52

Windows-specific problems 56

Support options 57

Obtaining software updates 57

FREQUENTLY ASKED QUESTIONS 58

CARE AND MAINTENANCE 60

Caring for the Cintiq 60

Replacing the pen nib 61

OTHER USEFUL INFORMATION 62

Uninstalling Cintiq 62

Managing preferences 63

Installing multiple tablets 64

Using applications integrated for tablet control 64

Importing expert settings 65

Product information 65

Product specifications 66

Warranty Service in the U.S.A. and Canada 66

Warranty Service Outside of the U.S.A.

and Canada 66

Ordering parts and accessories 67

GLOSSARY 68

Produkspesifikasjoner

Merke:	Wacom
Kategori:	Tegnebrett
Modell:	Cintiq Companion
Vekt:	1800 g
Bredde:	375 mm
Dybde:	248 mm
Høyde:	17 mm
Batterikapasitet:	64.4 Wh
Bluetooth:	Ja
Prosessorfrekvens:	1.9 GHz
Prosessorfamilie:	Intel® Core™ i7
Intern lagringskapasitet:	512 GB
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth-versjon:	4.0
GPS:	Nei
Frontkameraoppløsning (numerisk):	2 MP
Videoopptak:	Ja
Type bakkamera:	Enkeltkamera
Plattform:	Windows
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Maksimal videooppløsning:	- piksler
Innebygd mikrofon:	Ja
Internminne:	8 GB
Lagringsmedier:	SSD
Busstype:	DMI
PCI Express-konfigurasjoner:	1x8, 1x16, 2x4, 2x8
Kodenavn prosessor:	Ivy Bridge
Frontkamera:	Ja
Støttede instruksjonssett:	AVX
Intel® Insider™:	Ja
Intel® Enhanced Halt State:	Ja
Intel® Small Business Advantage (Intel® SBA):	Nei
Intel® 64:	Ja
Prosessorpakkestørrelse:	31.0 x 24.0 mm
Konfliktfri prosessor:	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Intel® Trusted Execution Technology:	Nei
Intel® Anti-Theft Technology (Intel® AT):	Ja
Prosessorkode:	SR0N6
Intel® Demand Based Switching:	Nei
Grafikkadapterfamilie:	Intel
Intel® Smart Cache:	Ja
Batteriteknologi:	Lithium Polymer (LiPo)
Integrert 4G WiMAX:	Ja
Prosessorgenerering:	3rd gen Intel® Core™ i7
Skjermoppløsning:	1920 x 1080 piksler
Produktfarge:	Black, Grey
Prosessorkjerner:	2
Internminnetype:	DDR3-SDRAM
Minnekortenhet:	MicroSD (TransFlash)
Skjermdiagonal:	13.3 "
LED-baklys:	Ja
Berøringsteknologi:	Multi-touch
Naturlig sideforhold:	16:9
Beste Wi-Fi-standard:	Wi-Fi 4 (802.11n)
Operativsystemprogramvare 04:	Windows 8 Pro
Batteriliv (maks.):	- timer
Hodetelefontilkobling:	3,5 mm
Hodetelefon ut:	Ja
Batterispenning:	7.4 V
Mikrofon, linje-inn-støpsel:	Nei
Innebygd kortleser:	Ja
Hurtigstartsguide:	Ja
Formfaktor:	Slate
prosessorprodusent:	Intel
Paneltype:	IPS
Enhetstype:	Tablet PC
Antall Mini DisplayPorts:	1
Prosessorstøpsel:	BGA 1023
Prosessor forsidebuss:	- MHz
Prosessormodell:	i7-3517U
Videokontakter:	HD Graphics 4000
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Systembussrate:	5 GT/s
Lysstyrke for skjerm:	210 cd/m²
Mobil HD-lenke (MHL):	Nei
Display antall farger:	16.78 million farger
AC-adapter bunt:	Ja
Bakkamera:	Ja
Bakkameraoppløsning (numerisk):	8 MP
Tastatur medfølger:	Nei
Intel® Wireless Display (Intel® WiDi):	Ja
Intel® Turbo Boost Technology:	2.0
Intel® Hyper Threading Technology (Intel® HT Technology):	Ja
Intel® My WiFi Technology (Intel® MWT):	Ja
Intel® Rapid Start Technology:	Nei
Intel® Smart Response Technology:	Nei
Intel® Smart Connect Technology:	Nei
Enhanced Intel SpeedStep Technology:	Ja
Boostfrekvens prosessor:	3 GHz
Processor cache:	4 MB
Cachetype prosessor:	Smart Cache
Prosessortråder:	4
Prosessorlitografi:	22 nm
Prosessorens driftmoduser:	64-bit
Stigning:	L1
Thermal Design Power (TDP):	17 W
Prosessorserier:	Intel Core i7-3500 Mobile series
Tjunction:	105 °C
Intel® Quick Sync Video Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® InTru™ 3D Technology:	Ja
Intel® Virtualization Technology (VT-x):	Ja
Integrerte alternativer tilgjengelige:	Nei
Intel® VT-x with Extended Page Tables (EPT):	Ja
Inaktive tilstander:	Ja
Thermal Monitoring Technologies:	Ja
Intel® AES New Instructions (Intel® AES-NI):	Ja
Intel Sikkerhets Nøkkel:	Ja
Execute Disable Bit:	Ja
Intel® FDI Technology:	Ja
Intel® Flex Memory Access:	Ja
Intel® Fast Memory Access:	Ja
Intel Virtualisering Technology for Directed I/O (VT-d):	Ja
Intel® Identity Protection Technology version:	1.00
Intel Secure Key Technology versjon:	1.00
Intel® Dual Display Capable Technology:	Ja
Processor ARK ID:	65714
CPU-multiplikator (buss/kjerneforhold):	19
Grafikk og IMC-litografi:	22 nm
64-bit beregning:	Ja
Pekepenn:	Ja
